Optos P200T E Series - Network Specification and Characteristics

Chapter 2 - Introduction
No. Name of Part Description
5 Status indicator
The color changes to show the status of the device, see Status indicator on
page50.
6 Touch screen
The touch screen monitor is used to interact with the system. It displays
alignment feedback and captured images.
7 Hand control
The hand control comprises buttons used to adjust the patient alignment and
capture images.
8 Image server
Runs the OptosAdvance software and lets you manage the networked images.
The image server will also let you review and analyze patient images.
9 Customer network
Switches, Firewalls, Internet access, Review clients, Virtual image server (if
required)
10
Patient
environment
The image server, switch and any browser-based review clients or monitors must
be positioned outside the patient environment; more than 1.5 meters (5 ft) from
the scan head.
Note
The device also includes a user guide, power cable and ethernet cable not shown on this diagram.
A table may also be supplied.
2.6.2 Network specification and characteristics
The following network specification is recommended when connecting the image server to a Wide Area
Network (WAN).
TABLE 1: Network specification
Network specification details
Installation Scan head and image server PC
Connection type LAN TCP/IP ipV4
Connection speed 1 Gbps recommended
Connection security All transport HTTPS by default
Connection ports (defaults) 443, 56620
Unused ports Locked on scan head and image server PC
