Chapter 4 - Technical Specification
The image server, switch and any browser-based review clients or monitors must be positioned outside the
patient environment; more than 1.5 meters (5 ft) from the scan head.
TABLE 10: Scan head dimensions
Dimension Details
Width 540 mm (22 inches)
Depth 570 mm (23 inches) including chin rest
Height 683 mm to 707 mm (27 inches to 28 inches)
Weight 45 kg (100 lbs) maximum
Door access width 760 mm (30 inches)
4.1.4 Review client properties
Browser-based review clients let you review and analyze patient images.
TABLE 11: Review client properties
Review clients
Display properties for browser-based review clients.
The minimum recommended monitor resolution. 1280 x 1024 pixels, 16.7 million colors.
Recommended browsers for OptosAdvance.
Google Chrome (46.0 and higher)
Internet Explorer (11.0 and higher)
Apple Safari (6.0 and higher)
4.1.5 Touch screen properties
The touch screen is powered from the scan head at +12V.
WARNING
Do not disconnect or connect the touch screen while the scan head is in use.
TABLE 12: Touch screen properties
Dimension Details
Minimum display resolution 1024 x 768 pixels, 16.7 million colors
Width 281 mm (11 inches)
Depth 20 mm (1 inch)
Height 234 mm (9.5 inches)
Weight less than 1.5 kg
Touch screen mount VESA MIS-D, 75, C (hole pattern: 75 mm x 75 mm)
Part Number: G110230/1ENG Page 61 of 72
Copyright 2019, Optos plc. All rights reserved. English
