Chapter 8 - Technical Specification
TABLE 13: Touch screen properties
Dimension Details
Minimum display
resolution
1024 x 768 pixels, 16.2 million colors
Width 281 mm to 339 mm (11 inches to 13.4 inches)
Depth 20 mm to 23 mm (1 inch)
Height 234 mm to 271 mm (9.5 inches to 10.7 inches)
Weight less than 2 kg
Touch screen mount
VESA MIS-D, 75, C (hole pattern: 75 mm x 75 mm)
May also include VESA MIS-D,100, C (hole pattern: 100 mm x 100 mm)
depending on specification.
9.1.6 Table requirements
WARNING
DoNOT plug the scan head into a power block or powered table. The scan head must be
plugged directly into a wall socket.
The scan head should be positioned in the middle of the table width. The front of the
scan head should be inline with the front of the table to allow the patient to get into the
correct alignment position.
The chin rest should slightly overhang the edge of the table.
The scan head and touch screen must be positioned on a table that meets the necessary safety standards.
The table MUST support the weight of the scan head.
TABLE 14: Table size requirements
Dimension Details
Width 887 mm (35 inches) (not including wheel position)
Depth 623 mm (24 inches) (not including wheel position)
Height 725 mm to 1205 mm (29 inches to 47 inches)
Where wheelchair accessibility is required the table must meet wheelchair accessibility standards.
9.1.7 Battery
CAUTION
Do NOT remove the scan head covers. Only Optos trained technical personnel are
permitted to service the device.
The device contains a 3V Lithium coin battery.
9.1.8 Environmental considerations (ambient)
Do NOT operate the device in an environment that exceeds the environmental limits (see Warnings and
cautions on page11).
