Install Replaceable Components in Motherboard Assembly
134 Oracle Database Appliance Service Manual • February 2016
See “Remove PCIe Card Cables From Secondary HBA PCIe Card” on page 126.
Caution - Equipment damage. The HBA data cables are delicate. Ensure that they are
removed and safely out of the way when servicing the motherboard.
■
Boot disk board cables.
See “Remove Boot Disk Backplane Cables” on page 130.
3.
Remove the following components from the server node.
■
Fan modules
“Remove a Fan Module” on page 55.
■
Boot disk drives
“Remove a Boot Drive” on page 52.
■
Boot disk drive backplane
“Remove Boot Disk Backplane” on page 103.
■
Memory modules (DIMMS)
“Remove Faulty DIMMs” on page 65.
■
PCIe riser and attached PCIe cards
“Remove PCIe Riser From Server Nodes” on page 72.
■
CPUs
“Remove Processor (CPU)” on page 97.
■
Internal PCIe card
“Remove PCIe Card Cables From Primary HBA PCIe Card” on page 124.
■
Battery
“Remove Battery” on page 83.
Install Replaceable Components in Motherboard Assembly
1.
Attach an antistatic wrist strap.
See “Performing Electrostatic Discharge and Antistatic Prevention Measures” on page 34.
2.
Install the following components into the server node.
■
Fan modules
See “Install a Fan Module” on page 56.
■
Boot disk drives
See “Install a Boot Drive” on page 53.
