Oracle EXADATA X6-2 User Manual

Figure 2-2 Network Diagram for Oracle Exadata Database Machine X4-2 and
Later Models
IB0 IB1 IB0 IB1
Oracle
Database Server
Management
Client Access
Private InfiniBand
Additional network 1 (optional)
NET2 NET1 NET0 NET0 ILOM ILOMNET3
PCI1 /
PORTA
Exadata
Storage Servers
InfiniBand
Switch
InfiniBand
Switch
Ethernet
Switch
BONDETH0
PDU A PDU B
PCI1 /
PORTB
The following image shows the default network diagram for Oracle Exadata Database
Machine X3-2 and Oracle Exadata Database Machine X2-2. Use the files from Oracle
Exadata Database Machine Deployment Assistant to verify the cable connections
when cabling Oracle Exadata Database Machine to the existing network.
Chapter 2
Overview of Network Requirements
2-5
