Configure RAID in Legacy Boot Mode
Note - To learn more about the RAID controller card referenced in this procedure, see https://
docs.broadcom.com/docs/pub-005110.
In the following procedure, drives 2 and 3 are used to create a RAID 1 volume.
1.
Power on or reset the host.
For example, to reset the host, do one of the following:
■
From the local server, press the Power button (approximately 1 second) on the front panel of
the server to power off the host, then press the Power button again to power it back on.
■
From the Oracle ILOM web interface, select Host Management > Power Control, then
select Reset from the Select Action list box.
■
From the Oracle ILOM CLI, type: reset /System
The boot messages appear.
2.
Type CTRL+R during the boot process to launch the BIOS Configuration Utility.
The LSI MegaRAID BIOS Configuration Utility appears.
3.
Review the listed drives determine which drives are available for logical drive
creation.
If this page includes a drive group where you want to install an OS, you can skip to Step 12.
Otherwise continue.
112 Oracle Server X6-2 Installation Guide • July 2020
