Note8) The baud rates of 300, 600 and 1200 bps can be specified by the SYS instruction only (Ver 2.0 or
later).
Communication specifications 2 Interface: Ethernet
Item
Specifications
Interface IEEE802. 3u, 10BASE-T/100BASE-TX
Connector shape: RJ45
Transmission
specifications
Baud rate 100 Mpbs/10 Mbps
Transmission method
Baseband
Max. segment length 100 m
Note1)
Communication cable
UTP (Category 5)
Protocol TCP/IP, UDP/IP, ICMP, ARP, DHCP
Function Auto-negotiation function
MDI/MDI-X Auto-crossover function
Note1) The length between a HUB and the module.
