7.4.3 Connection with 1:1 Communication (General-purpose serial
communication)
System register settings
Settings for COM1 port (AFPX-COM1, AFPX-COM2, AFPX-COM3, AFPX-COM5)
No.
Name
Set Value
No. 412 Selection of communication mode for
COM1 port
General-purpose serial communication
No. 413 Communication format for COM1 port Data length: ……
Parity check: …..
Stop bit: …………
Terminator: ……..
Header: …………
7 bits/8 bits
None/Odd/Even
1 bit/2 bits
CR/CR+LF/None/ETX
No STX/STX
No. 415
Baud rate setting for COM1 port
Note2)
2400 to 115200 bps
No. 416 Starting address for receive buffer for
COM1 port
DT0 to DT32764 (Initial value: DT0)
Note1)
No. 417
Receive buffer capacity for COM1 port
0 to 2048 words (Initial value: 2048 words)
Settings for COM2 port (AFPX-COM2, AFPX-COM4, AFPX-COM5, AFPX-COM6)
No.
Name
Set Value
No. 412 Selection of communication mode for
COM2 port
General-purpose serial communication
No. 414 Communication format for COM2 port Data length: ……
Parity check: …..
Stop bit: …………
Terminator: ……..
Header: …………
7 bits/8 bits
None/Odd/Even
1 bit/2 bits
CR/CR+LF/None/ETX
No STX/STX
No. 415 Baud rate setting for COM2 port
Note2)
2400 to 115200 bps
No. 418 Starting address for receive buffer for
COM2 port
DT0 to DT32764 (Initial value: DT2048)
Note1)
No. 419 Receive buffer capacity for COM2 port 0 to 2048 words (Initial value: 2048 words)
Note1) When using the C14, the values are DT0 to DT12285.
Note2) The baud rates of 300, 600 and 1200 bps can be specified by the SYS1 instruction (Ver 2.0 or
more). However, the setting value of the system register cannot be changed.
Note3) The setting values for the COM2 port of AFPX-COM6 are 9600 bps, 19200 bps and 115200 bps
only. The same baud rate should be specified by the cassette backside switch and the system
register.
