7.7.8 MEWTOCOL Master Communication Setting (Ver 1.10)
For using as the MEWTOCOL master, set the AFPX-COM5 to the computer link and client. Also,
specifying the simultaneous transmission by broadcast or the target IP address for unit number in the
option setting enables the communication with various PLCs.
MEWTOCOL master setting in TCP
Item
Default
Communication protocol
TCP
Action mode
Client connection
Baud rate (COM1)
15200 bps/9600 bps
Note)
Communication mode Computer link
Destination IP address
IP address of destination
Destination port No. 1025 to 32767
Source port No.
0, 1025 to 32767
Timeout 0 to 1800 secs
Retry time
0 to 1800 secs
Note1) Specify the same baud rate as the
communication environment setting of the
COM1 port of the FP-X.
Note:
If you want to transmit data when connection is not established, the connection can be established from
the AFPX-COM5 and data can be transmitted.
In the TCP, it takes some time for connection. The connection timeout for the AFPX-COM5 is the same
as the response timeout value. Set the timeout time for the SEND/RECV instruction longer than the
response timeout value to judge the connection timeout.
