Panasonic AFPX-C30T User Manual

Type of computer and suitable cable
For the connection between a personal computer (RS232C) and the control unit (RS232C)
PC side connector
PLC side connector
Specifications
Product No.
D-sub 9-pin
female-Mini DIN round 5-pin
L type (3 m)
AFC8503
female-Mini DIN round 5-pin Straight type (3 m) AFC8503S
Note) Note) A USB/RS232C conversion cable is necessary to connect the unit to the USB port of a
personal computer using a PC connection cable.
For the connection between a personal computer (USB) and the control unit (USB)
USB cable (For C30 and C60 only)
Use a commercial cable.
Cable type
Length
USB 2.0 (or 1.1) AB type
Max. 5 m
