FP-X
Item
Add-
ress
Name
Default
value
Description
COM.
2 port
set-
ting
411
Unit No. setting
1
1 to 99
412
Communication mode
setting
Computer
link
Computer link
General-purpose serial communication
MODBUS RTU
Selection of modem
connection
Disabled Enabled/Disabled
Selection of port Built-in USB
Built-in USB
Communication cassette
414
Communication
format setting
Data length
bit: 8 bits
Parity check:
“with odd”
Stop bit: 1 bit
Enter the settings for the various items.
- Data length bit: 7 bits/8 bits
- Parity check: none/odd/even
- Stop bit: 1 bit/2 bits
- The following setting is valid only when
the communication mode specified by
system register 412 has been set to
“General-purpose serial communication”.
- Terminator: CR/CR+LF/None
-
Header: STX not exist/STX exist
415 Baud rate setting 9600 bps
2400 bps
4800 bps
9600 bps
19200 bps
38400 bps
57600 bps
115200 bps
416
Starting address for
received buffer of
general (serial data)
communication mode
2048 0 to 32764
417
Buffer capacity
setting for data
received of general
(serial data)
communication mode
2048 0 to 2048
Note1) The communication format in a PC(PLC) link is fixed at the following settings:
the data length is 8 bits, odd parity, stop bit is 1.
The communication speed (baud rate) is fixed at 115200 bps.
Note2) The USB port for C30 and C60 can be selected by the system register setting.
The USB port has been selected for the COM2 port of C30 and C60 as default setting. The USB
port is 115.2 kbps despite of the baud rate setting No. 415.
The setting for No. 412 must be changed to communication cassette for using the COM2 port of
the communication cassette.
The COM2 port of the USB port and the communication cassette cannot be used at the same time.
