FP-X Ry type FP-X (A: Available, N/A: Not available)
Address Name Description
Read-
ing
Writ-
ing
DT90348
Elapsed
value
area
Lower words
PLS-CH0
Counting area for output
(Y100, Y101) of the pulse I/O
cassette.
A A
Note)
DT90349 Higher words A A
Note)
DT90350
Target
value
area
Lower words
The target value is set when
instructions F171 (SPDH),
F172 (PLSH), F174 (SP0H)
and F175 (SPSH) are
executed.
A A
Note)
DT90351 Higher words A A
Note)
DT90352
Elapsed
value
area
Lower words
PLS-CH1
Counting area for output
(Y200, Y201) of the pulse I/O
cassette.
A A
Note)
DT90353 Higher words A A
Note)
DT90354
Target
value
area
Lower words
The target value is set when
instructions F171 (SPDH),
F172 (PLSH), F174 (SP0H)
and F175 (SPSH) are
executed.
A A
Note)
DT90355 Higher words A A
Note)
DT90356
Not used
-
N/A
N/A
DT90357
Not used
- N/A N/A
DT90358
Not used
-
N/A
N/A
DT90359
Not used
- N/A N/A
DT90360
Control flag monitor
area
HSC-CH0
When HSC control is executed
by F0 (MV)S, DT90052
instruction, the setting value
for the target CH is stored in
each CH.
A
N/A
DT90361
HSC-CH1
A N/A
DT90362
HSC-CH2
A
N/A
DT90363
HSC-CH3
A N/A
DT90364
HSC-CH4
A
N/A
DT90365
HSC-CH5
A N/A
DT90366
HSC-CH6
A
N/A
DT90367
HSC-CH7
A N/A
DT90368
HSC-CH8
A
N/A
DT90369
HSC-CH9
A N/A
DT90370
HSC-CHA
A
N/A
DT90371
HSC-CHB
A N/A
DT90372
PLS-CH0
A
N/A
DT90373
PLS-CH1
A N/A
Note) Writing in the elapsed value area is available by F1 (DMV) instruction only.
Writing in the target value area is available by F171 (SPDH), F172 (PLSH), F174 (SP0H) and
F175 (SPSH) instructions only.
