PACD011001C2 Test Operation
Test Operation Urban Multi “MX1, ME1 Series” Using R-22 117
A Group of Indoor
Units
1. 1 indoor unit with no remote controller
2. 1 indoor unit controlled by either 1 or 2 remote controllers
3. Max. 16 indoor units controlled by either 1 or 2 remote controllers
Zone Control by
Central Remote
Controller
A “zone” is a collection of 1 or more groups.
Zone control lets you make settings for several groups simultaneously in order to facilitate the task of
setting.
By setting once, everything in the zone becomes set to the same setting. The number of zones that can be
set by the central remote controller is MINI~MAX 64 zones. (The number of groups in 1 zone is MINI~MAX
64 groups.) The manner of linking zones can be set as desired with the central remote controller.
