Interface Adaptor PACD011001C2
608 Appendix
6.4 Interface Adaptor for Urban Split Series (CZ-102AP11P)
<Objective / use>
The interface adaptor for US series lets you connect optional controllers for centralised control (central
remote controller, unified ON/OFF controller, schedule timer) with US.
„
Part Names and Functions
<System Outline>
If using UM System Inverter in common with transmission line, connect either A indoor-to-outdoor unit
transmission wiring or B outdoor-to-outdoor unit transmission wiring.
