PACD011001C2 Test Operation
Test Operation Urban Multi “MX1, ME1 Series” Using R-22 123
1.23 Unified ON/OFF Controller (CZ-01ANA11P)
Turns each group of indoor units on/off individually or simultaneously for up to 16 groups (128 units), and
lets you check the operation/malfunction display all at once at a glance.
‹
Lets you turn up to 16 groups of indoor units (128 units) on/off simultaneously or individually, and lets
you check the operation/malfunction display all at once at a glance.
‹
By combining with a central remote controller or schedule timer, you can build a system that matches
scale and use .
‹
Features compact size casing with thickness of only 16 mm. (Uses JIS recessed box for 2)
‹
Wiring can be extended up to 1 km. For the wiring method, bus type and star type wiring crossover
wiring can be used as well as crossover wiring.
1.23.1 System Configuration
Up to 16 groups of indoor units can be turned on/off individually or simultaneously by unified ON/OFF
controller. Also lets you connect with an outside key system or host computer monitor panel by forced OFF
input (no-voltage a contact).
(This optional accessory cannot be used in combination with optional accessory BMS interface adaptor for
individual and unified control, for unified group.)
