List of Safety Device and Function Parts Setting Value PACD011001C2
422 Function UM Combination “MA1R Series” Using R-407C
2.2 Indoor Unit
Parts Name Symbol
Model
Remark
CS-32
UMHPP
CS-40
UMHPP
CS-50
UMHPP
CS-63
UMHPP
CS-80
UMHPP
CS-100
UMHPP
CS-125
UMHPP
Remote
Controller
Wired Remote Controller CZ-01RT11P Option
Wireless Remote
Controller
CZ-01RWU12P Option
Motors
Fan Motor M1F
AC 220~240V 45W 6P AC 230V 90W 6P
Thermal protector 130°C : OFF 80°C : ON
Motor for Drain Pump M1P
AC220-240V (50Hz) AC220V (60Hz)
Thermal Fuse 145°C
Swing Motor M1S
MP35HCA[3P007482-1]
Stepping Motor DC16V
Thermistors
Thermistor (Suction Air) R1T
ST8601-1
φ
4 L250
20k
Ω
(25°C)
Thermistor (for Heat
Exchanger High Temp.)
R3T
ST8605-4
φ
8 L800
20k
Ω
(25°C)
Thermistor (Heat
Exchanger)
R2T
ST8602-4
φ
6 L800
20k
Ω
(25°C)
Others
Float Switch 33H FS-0211
Fuse F1U 250V 5A
φ
5.2
Thermal Fuse TFu 109°C 10A
Transformer T1R TR22M21R8
Parts Name Symbol
Model
Remark
CS-20
LMHPP
CS-25
LMHPP
CS-32
LMHPP
CS-40
LMHPP
CS-50
LMHPP
CS-63
LMHPP
CS-80
LMHPP
CS-125
LMHPP
Remote
Controller
Wired Remote Controller CZ-01RT11P Option
Wireless Remote
Controller
CZ-01RWL12P Option
Motors
Fan Motor M1F
AC 220~240V 50Hz
1
φ
10W 1
φ
15W 1
φ
20W 1
φ
30W 1
φ
50W 1
φ
85W
Thermal Fuse 152°C
—
Thermal protector
135°C : OFF
87°C : ON
Motor for Drain Pump M1P
AC220-240V (50Hz)
Thermal Fuse 169°C
Swing Motor M1S
MT8-L[3PA07509-1]
AC200~240V
Thermistors
Thermistor (Suction Air) R1T
ST8601-16
φ
4 L1250
20k
Ω
(25°C)
Thermistor (for Heat
Exchanger High Temp.)
R3T
ST8605-6
φ
8 L1250
20k
Ω
(25°C)
Thermistor (Heat
Exchanger)
R2T
ST8602-5
φ
6 L1000
20k
Ω
(25°C)
Others
Float Switch 33H FS-0211
Fuse F1U 250V 5A
φ
5.2
Transformer T1R TR22M21R8
Parts Name Symbol
Model
Remark
CS-25DM1HPK CS-32DM1HPK CS-40DM1HPK CS-63DM1HPK
Remote
Controller
Wired Remote Controller CZ-01RT11P Option
Motors
Fan Motor M1F
AC 220~240V 50Hz
1
φ
15W 4P 1
φ
20W 4P 1
φ
45W 4P
Thermal Fuse 146°C Thermal protector 120°C : OFF 105°C : ON
Motor for Drain Pump M1P
AC 220-240V (50Hz)
Thermal Fuse 145°C
Swing Motor M1S
MT8-L[3PA07312-1]
AC200~240V
Thermistors
Thermistor (Suction Air) R1T
ST8601-13
φ
4 L630
20k
Ω
(25°C)
Thermistor (for Heat
Exchanger High Temp.)
R3T
ST8605-7
φ
8 L1600
20k
Ω
(25°C)
Thermistor (Heat
Exchanger)
R2T
ST8602A-7
φ
6 L1600
20k
Ω
(25°C)
Others
Float Switch 33H FS-0211
Fuse F1U 250V 5A
φ
5.2
Transformer T1R TR22M21R8
