PACD011001C2 Test Operation
Test Operation UM Combination “MA1R Series” Using R-407C 479
1.14 Contents of Control Modes
Twenty modes consisting of combinations of the following five operation modes with temperature and
operation mode setting by remote controller can be set and displayed by operation modes 0 through 19.
‹
ON/OFF control impossible by remote controller
Used when you want to turn on/off by central remote controller only.
(Cannot be turned on/off by remote controller.)
‹
OFF control only possible by remote controller
Used when you want to turn on by central remote controller only, and off by remote controller only.
‹
Centralized
Used when you want to turn on by central remote controller only, and turn on/off freely by remote
controller during set time.
‹
Individual
Used when you want to turn on/off by both central remote controller and remote controller.
‹
Timer operation possible by remote controller
Used when you want to turn on/off by remote controller during set time and you do not want to start
operation by central remote controller when time of system start is programmed.
How to Select
Operation Mode
Whether operation by remote controller will be possible or not for turning on/off, controlling temperature or
setting operation mode is selected and decided by the operation mode given on the right edge of the table
below.
Do not select “timer operation possible by remote controller” if not using a remote controller. Operation by
timer is impossible in this case.
∗
1. Factory setting
ON by remote
controller
(Unified ON by
central remote
controller)
OFF by remote
controller
(Unified OFF by
central remote
controller)
Temperature
control by
remote controller
Operation mode
setting by
remote controller
OFF by
remote
controller
Control
mode is "1."
Example
↓
Rejection
↓
Rejection
↓
Rejection
↓
Acceptance
↓
Acceptance
(VL069)
Control mode Control by remote controller Control
mode
Operation OFF Temperature
control
Operation
mode
setting
Unified operation, individual
operation by central remote
controller, or operation
controlled by timer
Unified OFF, individual stop
by central remote controller,
or timer stop
ON/OFF control
impossible by
remote controller
Rejection (Example) Rejection (Example) Rejection
(Example)
Rejection Acceptance 0
Rejection 10
Acceptance
(Example)
Acceptance
(Example)
1(Example)
Rejection 11
OFF control only
possible by remote
controller
Acceptance Rejection Acceptance 2
Rejection 12
Acceptance Acceptance 3
Rejection 13
Centralised Acceptance Rejection Acceptance 4
Rejection 14
Acceptance Acceptance 5
Rejection 15
Individual Acceptance Rejection Acceptance 6
Rejection 16
Acceptance Acceptance 7
∗
1
Rejection 17
Timer operation
possible by remote
controller
Acceptance
(During timer at ON position
only)
Acceptance
(During timer at ON position
only)
Rejection Acceptance 8
Rejection 18
Acceptance Acceptance 9
Rejection 19
To Next Page
