Test Operation PACD011001C2
478 Test Operation UM Combination “MA1R Series” Using R-407C
Group No. Setting
Example
„
If you have to set the address for each unit for calculating cost, etc., set the mode No. to “30.”
Caution
When turning the power supply on, the unit may often not accept any operation while "88" is displaying
after all indications were displayed once for about 1 minute on the liquid crystal display.
This is not an operative fault.
Centoral Remote
Controller
F1 F2
F1 F2 F1 F2
F1 F2
P1 P2
RC
RC
RC RC RC
F1 F2 P1 P2 F1 F2 P1 P2 F1 F2 P1 P2
F1 F2 P1 P2 F1 F2 P1 P2 F1 F2 P1 P2 F1 F2 P1 P2
No Remote Controller
Group Control by Remote Contoller
(autmatic unit address)
1-03
1-00
1-01
Main Sub
1-02
1-04
Indoor/Outdoor
Outdoor/Outdoor
F1 F2 F1 F2
Indoor/Outdoor
Outdoor/Outdoor
(V0917)
To Next Page
