Panasonic CU-8ME1XPK - List of Safety Devices and Functional Parts Setting Values

Function PACD011001C2
234 Function Urban Multi “MX1R, ME1R Series” Using R-407C
1.2 List of Safety Devices and Functional Parts Setting Values
1.2.1 CU-5·8·10MX1SPP
Item Symbol Name Type
CU-5MX1SPP CU-8MX1SPP CU-10MX1SPP
Comp-
ressor
Inverter side
Model Output
JT100BEVYE 3.5 kW JT100BEVTYE 3.5 kW JT100BEVTYE 3.5 kW
Standard side — JT100BETYE 2.2 kW JT160BETYE 3.75 kW
Compressor safety
thermostat
Discharge pipe thermistor 135°C OFF
J1HC/
J2HC
Crank case heater 33W 33W+33W
F2C Over-current relay — HOE-20F-TRA1 10A HOE-20F-TRA1 13A
Safety
device
Q1M
Q2M
Fan motor 190W 140W+230W 190W+230W
Safety thermostat Open 135 ± 5°C 140 W: Open 120 ± 5°C, 190W: 135 ± 5°C, 230 W: 135 ± 5°C
S1P Pressure switch
(for high pressure
safety)
20SP-688-6
OFF:31.5+0~-1.0kg/cm
2
ON:22.0+1.0~-1.0kg/cm
2
—
S1PH Pressure switch
(for high pressure
safety)
— 20SP - 688 - 6
OFF:31.5+0~-1.0kg/cm
2
ON:22.0+1.0~-1.0kg/cm2
S2PH Pressure switch
(for high pressure
safety)
— 20SP - 688 - 6
OFF:31.5+0~-1.0kg/cm
2
ON:22.0+1.0~-1.0kg/cm
2
Fusible plug FPG-3D 7~75°C
Sensor SENPH Pressure sensor PS8030A 0~34kg/cm
2
(0~3.3MPa)
SENPL Pressure sensor PS8030A 0~10kg/cm
2
(0~0.98MPa)
R1T Thermistor
(for outdoor air)
3.5~360K
Ω
R2T Thermistor
(for heat exchange)
3.5~400K
Ω
R3T Thermistor
(for discharge pipe)
3.5~400K
Ω
—
R3-1T Thermistor
(for inverter
discharge pipe)
— 3.5~400K
Ω
R3-2T Thermistor
(for standard
discharge pipe)
— 3.5~400K
Ω
R4T Thermistor
(for suction pipe)
3.5~360K
Ω
R5T Thermistor
(for inverter oil
temperature)
— 3.5~400K
Ω
Other
functions
/parts
Y1E Electronic
expansion
valve
When
cooling
ON: 2,000 pulses (completely open); OFF: 0 pulses (completely closed)
When
heating
ON: PI control; OFF: 0 pulses (completely closed)
Y2S Solenoid valve
(for hot gas bypass)
NEV603
Y3S Solenoid valve
(for inverter
injection)
NEV202
Y4S Solenoid valve
(for standard
injection)
— NEV202
