PACD011001C2 Function
Function Urban Multi “MX1R, ME1R Series” Using R-407C 235
1.2.2 CU-8·10 ME1XPK
Item Symbol Name Type
CU-8ME1XPK CU-10ME1XPK
Comp-
ressor
Inverter
side Model
Output
3
φ
,
380~
415V
INV JT100BAVTYE 3.5 kW JT100BAVTYE 3.5 kW
STD JT100BATYE 2.2 kW JT160BATYE 3.75kW
Compressor safety
thermostat
Discharge pipe thermistor 135°C OFF
J1HC/
J2HC
Crank case heater 33W+33W
F2C Over-current
relay
3
φ
,
380~415V
HOE-20F-TRA1
10A
HOE-20F-TRA1
13A
Safety
device
Q1M
Q2M
Fan motor 140W+230W 190+230W
Safety thermostat 140W: Open 120 ± 5°C, 190W: 135°± 5°C, 230W: 135 ± 5°C
S1PH Pressure switch (for high
pressure safety)
20SP-688-8 OFF: 3.09 MPa
ON: 2.16±0.1MPa
S2PH Pressure switch (for high
pressure safety)
20SP-688-8 OFF: 3.09 MPa
ON: 2.16±0.1MPa
Fusible plug FPG-3D 70~75°C
Sensor SENPH Pressure sensor PS8030A 0~3.3MPa
SENPL Pressure sensor PS8030A 0~10kg/cm
²
(0~0.98MPa)
R1T Thermistor (for outdoor air) 3.5~360K
Ω
R2-1T
R2-2T
Thermistor
(for heat exchange)
3.5~360K
Ω
R3-1T Thermistor (for inverter
discharge pipe)
3.5~400K
Ω
R3-2T Thermistor (for standard
discharge pipe)
3.5~400K
Ω
R4-1T
R4-2T
Thermistor
(for suction pipe)
3.5~360K
Ω
R5T Thermistor
for inverter oil temperature)
3.5~360K
Ω
Other
functions
/parts
Y1E Electronic
expansion valve
When
cooling
ON: 2,000 pulses (Fully open); OFF: 0 pulses (Fully closed)
When
heating
ON: PI control; OFF: 0 pulses (Fully closed)
Y1S Solenoid valve
(pressure equalizing)
BPV-1706
Y2S Solenoid valve
(for hot gas bypass)
NEV603
Y3S Solenoid valve
(for inverter injection)
NEV202
Y4S Solenoid valve
(for standard injection)
NEV202
Y5S Solenoid valve
(for discharge gas)
SEV-1506
Y6S Solenoid valve
(for liquid pressure)
NEV603
+0
–0.1
+0
–0.1
