606 Appendix
6.3 Signal Output Adaptor PCB for Optional Accessory (KRP1B61 / KRP1B2 /
KRP1B3)
<Objective / use>
Enables you to fetch compressor and fan operation output when optional accessories (auxiliary electric
heater, humidifier, fresh air intake kit [with fan duct]) are installed.
6.3.1 Part Names and Functions
KRP1B61 / KRP1B2
KRP1B3
