Panasonic CU-8ME1XPK - Outline of Control (ME1 Series)

PACD011001C2 Function
Function Urban Multi “MX1, ME1 Series” Using R-22 25
1.4 Outline of Control (ME1 Series)
1.4.1 Inverter Compressor, Motorized PI Control
1. Compressor PI control
„
Cooling operation
Controls TeS (target Te value) at constant ··· Constant-level control of Te (low pressure equivalent
saturation temperature)
TeS = 5.5°C
„
Heating operation
Controls TcS (target Tc value) at constant ··· Constant-level control of Tc (high pressure equivalent
saturation temperature)
TcS = 48°C
„
Simultaneous cooling/heating operations
Controls TeS and TcS at constant
TeS = 5.5°C
TcS = 48°C
∗
TeS setting values
* TcS setting values
2. Motorized valve PI control
Provides PI control for the motorized valves (Y1E and Y2E) to maintain a constant superheat (SH) level at
the outlet of the outdoor heat exchanger (evaporator).
SHs = Ts - Te
SHs = 5°C
∗
Ts1 :Suction pipe temperature (R4-1T)
Ts2: Suction pipe temperature (R4-2T)
3. Heat exchanger PI control
Provides PI control for the motorized valve (Y1E) to maintain TeS and TcS at constant.
Motorized valve mode
LM
(Factory setting)
H
2.5 5.5 8.5
LM
(Factory setting)
H
43 46 49
EV mode Initial opening Max. opening Min. opening Normal opening
1 Y1E 2000 2000 2000 Fixed at 2000
Y2E 2000 2000 2000 Fixed at 2000
2 Y1E 2000 2000 1400 Heat exchanger PI control
Y2E 0 0 0 Fixed at 0
3 Y1E 750 1400 100 Heat exchanger PI control
Y2E 250 400 100 Motorized valve PI control
4 Y1E 0 0 0 Fixed at 0
Y2E 700 1000 100 Motorized valve PI control
5 Y1E 700 2000 100 Motorized valve PI control
Y2E 500 2000 100 Motorized valve PI control
