PACD011001C2 Test Operation
Test Operation Urban Multi “MX1, ME1 Series” Using R-22 131
1.25.2 Connection for Optional Controller for Centralised Control
You can use any combination of two central remote controller, one schedule timer, and from one to eight
unified ON/OFF controllers. The maximum number of units for a single system is 128.
Central remote controller
CZ-01ESM11P
Unified ON/OFF remote controller
CZ-01ANA11P
Schedule timer
CZ-01ESW11P
2——
21—
22 ~ 8—
2—1
211
22 ~ 81
—1—
—2 ~ 8—
—1 1
—2 ~ 8 1
—— 1
