PACD011001C2 Function
Function Urban Multi “MX1R, ME1R Series” Using R-407C 259
Low Outdoor Air
Cooling in
Conditions (Step 2)
Normal operation
Step 2
• Cooling with compressor running
(doesn't include oil return)
&
• High pressure < 8.0 kg/cm²
(0.784 MPa)
&
• Radiator fin temperature < 67˚C
• Compressor off
or
•
Other than cooling (includes oil return)
or
• High pressure > 17.3 kg/cm²
(1.690 MPa)
or
• Radiator fin temperature > 87˚C
Conditions satisfied
Conditions satisfied
(M018)
To Next Page
