PACD011001C2 Test Operation
Test Operation Urban Multi “MX1R, ME1R Series” Using R-407C 301
<Control input specifications>
„
Input signal
Constant contact a
Input current is approx. 12 - 24 VDC, 10 mA per contact.
Use a micro-current contact for the relay contact.
(Max. 12 VDC, 1 mA)
„
Outside wiring specifications
Recommended electric wiring: Sheathed vinyl cord or cable 0.75
~
1.25 mm² (double core)
Wiring length: Max. 150 m
Run separate from power line in order to prevent malfunction.
„
Installation positions
Model/series Installation box/plate Installation position
Outdoor
unit
Function unit Not necessary Inside main unit's electric box
Indoor unit
CS-UM KRP1B98
∗
Regarding installation position,
see the page describing the
remote group control adaptor
CS-LM KRP1B96
CS-DM
CS-FM
CS-EM
Not necessary
CS-TM KRP1B93
CS-KM Not necessary
CS-PM/CS-RM
CZ-HR Not necessary Inside main unit's electric box
To Next Page
