PACD011001C2 Test Operation
Test Operation Urban Multi “MX1R, ME1R Series” Using R-407C 317
2. The mode numbers inside parentheses cannot be used by wireless remote controllers, so they cannot
be set individually. Setting changes also cannot be checked.
3. Mode numbers 17 (27) and 19 (29) are HRV functions that can be set from a UM Series remote
controller.
4. The second code No. is factory set to “01.” The field set air flow direction position and thermostat sensor
in remote controller is however set to “02,” and ventilation fan speed is set to “05.”
5. Do not make settings other than those described above. Nothing is displayed for functions the indoor
unit is not equipped with.
6. “88” may be displayed to indicate the remote controller is resetting when returning to the normal mode.
1.15.3 Setting Contents and Code No.
UM
Series
indoor
unit
settings
Mode
No.
Note 2
First
Code
No.
Setting Contents Second Code No.(Note 3)
01 02 03 04
10(20) 0 Filter contamination heavy/light
(Setting for display time to
clean air filter)
(Sets display time to clean air
filter to half when there is
heavy filter contamination.)
Super
long life
filter
Light Approx.
10,000
hrs.
Heavy Approx.
5,000
hrs.
——
Long life
filter
Approx.
2,500
hrs.
Approx.
1,250
hrs.
Standard
filter
Approx.
200 hrs.
Approx.
100 hrs.
1 Long life filter type
(CS-LM only, 01 indicates long life)
Long life filter Super long life filter
—
Soot filter
2 Thermostat sensor in remote controller Use No use
—
3 Display time to clean air filter calculation
(Set when filter sign is not to be displayed.)
Display No display
—
12(22) 0 Optional accessories output selection (field
selection of output for adaptor for wiring)
Indoor unit turned
ON by thermostat
Operati on outpu t Malf unction output
1 ON/OFF input from outside (Set when ON/
OFF is to be controlled from outside.)
Forced OFF ON/OFF control External protection
device
—
2 Thermostat differential changeover
(Set when remote sensor is to be used.)
CS-LM, CS-UM, CS-DM, CS-TM only
1°C 0.5°C
——
3 OFF by thermostat fan speed LL Set fan speed
——
4 Automatic mode differential (automatic
temperature differential setting for UM
inverter series “ME1R Series” cool/heat)
01:0 02:1 03:2 4:03 05:4 6:05 7:06 08:7
5 Power failure automatic reset Not equipped Equipped
——
13(23) 0 High air outlet velocity
(Set when installed in place with ceiling
higher than 2.7 m.) CS-UM only
NH
——
1 Selection of air flow direction
(Set when a blocking pad kit has been
installed.) CS-UM only
F (4 directions) T (3 directions) W (2 directions)
—
2 Horizontal air discharge Equipped Not equipped
——
3 Air flow direction adjustment (Set at
installation of decoration panel.) CS-DM
only
Equipped Not equipped
——
4 Field set air flow position setting Draft prevention Standard Ceiling Soiling
prevention
—
5 Field set fan speed selection
(fan speed control by air discharge outlet
for phase control)
Standard Optional
accessory 1
Optional accessory
2
—
6 Static pressure selection (for setting static
pressure for ducts and others
Standard
High static pressure Low static pressure
—
15(25) 1 Thermostat OFF excess humidity Not equipped Equipped
——
3 Drain pump humidifier interlock selection Not equipped Equipped
——
4 Sets whether filter sign is to be output by
time or by input.
Time addition Input
——
5 Field set selection for individual ventilation
setting by remote controller
Not equipped Equipped
——
6 Field set selection for individual ventilation
setting by remote controller
Not equipped Equipped
——
To Next Page
