PACD011001C2 Function
Function Urban Multi “MX1, ME1 Series” Using R-22 19
1.2.2 CU-8·10ME1XPA
Item Symbol Name Type
CU-8ME1XPA CU-10ME1XPA
Comp-
ressor
Inverter
side Model
Output
3
φ
,
380~415V
INV JT100BAVTYE 3.5 kW JT100BAVTYE 3.5 kW
STD JT100BATYE 2.2 kW JT160BATYE 3.75kW
Compressor safety thermostat Discharge pipe thermistor 135°C OFF
J1HC/
J2HC
Crank case heater 33W+33W
F2C Over-current
relay
3
φ
, 380~415V HOE-20F-TRA1
10A
HOE-20F-TRA1
13A
Safety
device
Q1M
Q2M
Fan motor 140W+230W
Safety thermostat 140W: Open 120 ± 5°C, 230W: 135 ± 5°C
S1PH Pressure switch (for high
pressure safety)
20SP-688-6 OFF: 27.5+0~–1.0kg/cm
2
ON: 20.0+1.0~–1.0kg/cm
²
S2PH Pressure switch (for high
pressure safety)
20SP-688-6 OFF: 27.5+0~–1.0kg/cm
2
ON: 20.0+1.0~–1.0kg/cm
²
Fusible plug FPG-3D 70~75°C
Sensor SENPH Pressure sensor PS8030A 0~30kg/cm
²
(0~2.94MPa)
SENPL Pressure sensor PS8030A 0~10kg/cm
²
(0~0.98MPa)
R1T Thermistor (for outdoor air) 3.5~360K
Ω
R2-1T
R2-2T
Thermistor
(for heat exchange)
3.5~360K
Ω
R3-1T Thermistor (for inverter discharge
pipe)
3.5~400K
Ω
R3-2T Thermistor (for standard
discharge pipe)
3.5~400K
Ω
R4-1T
R4-2T
Thermistor
(for suction pipe)
3.5~360K
Ω
R5T Thermistor
for inverter oil temperature)
3.5~360K
Ω
Other
functions
/parts
Y1E Electronic
expansion valve
When
cooling
ON: 2,000 pulses (Fully open); OFF: 0 pulses (Fully closed)
When
heating
ON: PI control; OFF: 0 pulses (Fully closed)
Y1S Solenoid valve
(pressure equalizing)
BPV1706
Y2S Solenoid valve
(for hot gas bypass)
NEV603
Y3S Solenoid valve
(for inverter injection)
NEV202
Y4S Solenoid valve
(for standard injection)
NEV202
Y5S
Y7S
Solenoid valve
(for discharge gas)
NEV603
Y6S Solenoid valve
(for liquid pressure)
NEV603
