CNP101 DZFC000013 CONNECTOR
CNP102 DZFC000052 PH CONNECTOR
CNP103 DZFC000564 CONNECTOR
CNP104 DZFC000323 CONNECTOR
CNP106 DZFC000334 CONNECTOR
CNP107 DZFA000093 DIMM SOCKET
CNP108 DZFC000038 CONNECTOR
CNP110 DZFC000047 CONNECTOR
CNP111 DZZZ999999 Not Mounted
CNP112 DZFC000035 PH CONNECTOR
CNP113 DZZZ999999 Not Mounted
CNP114 DZFC000047 CONNECTOR
CNP117 DZFC000056 CONNECTOR
CNP118 DZFC000041 PH CONNECTOR
CNP120 DZFC000565 CONNECTOR
CNP121 DZFC000313 CONNECTOR
CNP122 DZFC000571 CONNECTOR
CNP123 DZFC000322 CONNECTOR
CNP124 DZZZ999999 Not Mounted
CNP125 DZFC000041 PH CONNECTOR
CP1 DZDW000070 FUSE
CP2 DZDW000066 FUSE
CP3 DZDW000066 FUSE
CP4 DZDW000066 FUSE
CP5 DZDW000066 FUSE
CP6 DZDW000066 FUSE
CP7 DZDW000070 FUSE
CP8 DZDW000070 FUSE
D1 DZZZ999999 Not Mounted
D10 DZAG000023 DIODE
D11 DZAG000023 DIODE
D12 MA786 DIODE
D2 DZZZ999999 Not Mounted
D3 DZZZ999999 Not Mounted
D4 DZZZ999999 Not Mounted
D5 MA786 DIODE
D6 DZAH000013 DIODE
D7 MA786 DIODE
D8 MA721 DIODE
D9 MA152A DIODE
DA1 DZZZ999999 Not Mounted
DA3 MA724 SCHOTTKY BARRIER DIODE
IC1 DZAC000208 16BIT MICROCONTROLER
IC10 DZZZ999999 Not Mounted
IC11 DZAA001060 FLASH MEMORY
or DZAA001091 FLASH MEMORY
IC12 DZAA001154 FLASH MEMORY
IC13 DZZZ999999 Not Mounted
IC14 DZAC000020 GATE ARRAY
IC15 DZAA000977 VHCMOS
or DZAA000727 VHCMOS
IC16 DZAA000977 VHCMOS
or DZAA000727 VHCMOS
IC17 DZAA000977 VHCMOS
or DZAA000727 VHCMOS
IC18 DZAA000977 VHCMOS
or DZAA000727 VHCMOS
IC19 DZZZ999999 Not Mounted
IC2 DZAA000978 OCTAL BUS BUFFER
IC20 DZZZ999999 Not Mounted
IC21 DZZZ999999 Not Mounted
IC22 DZZZ999999 Not Mounted
IC23 DZZZ999999 Not Mounted
IC24 DZZZ999999 Not Mounted
IC25 DZZZ999999 Not Mounted
IC28 DZAC000234 GATE ARRAY
Safety
Mark
Ref. No. Part Number Part Name Description
