IC29 DZAA001102 SD-RAM
IC3 DZAA000095 TRIPLE INVERTER
IC30 DZAA001101 SD-RAM
or DZAA001339 SD-RAM
or DZAA001337 SD-RAM
or DZAA001338 SD-RAM
IC31 DZAA001101 SD-RAM
or DZAA001339 SD-RAM
or DZAA001338 SD-RAM
or DZAA001337 SD-RAM
IC32 DZZZ999999 Not Mounted
IC33 DZZZ999999 Not Mounted
IC34 DZZZ999999 Not Mounted
IC35 DZZZ999999 Not Mounted
IC36 DZZZ999999 Not Mounted
IC37 DZAA000978 OCTAL BUS BUFFER
IC38 DZAA000650 TRIPLE INVERTER
IC39 DZAA000978 OCTAL BUS BUFFER
IC4 DZAA000114 RESETTING IC
IC40 DZAA001098 MULTIPLEXER
IC41 DZAA001099 MULTIPLEXER
IC42 DZAA001083 MULTIPLEXER
IC46 DZAA001058 PWM
IC47 DZAA001075 NOR GATE
IC48 DZZZ999999 Not Mounted
IC49 DZAA001072 LVDS
IC5 DZAC000166 GATE ARRAY
IC50 DZZZ999999 Not Mounted
IC51 MN86076 GATE ARRAY
IC52 DZAA000095 TRIPLE INVERTER
IC53 DZZZ999999 Not Mounted
IC54 AN2190FHQ DIGITAL COPY SIGNAL PROCESSER
IC55 AN8133FHQ A/D CONVERTER
IC56 DZAA000295 AND GATE
IC57 DZAA001081 LMOS
IC58 DZAA000295 AND GATE
IC59 DZAA001201 LINEAR REGULATOR
IC6 DZAA000769 LMOS
IC60 DZAA001104 REGYULATOR
IC61 DZAA000510 3-TERMINAL POSITIVE VOLTAGE REGULATOR
IC62 DZAA000978 OCTAL BUS BUFFER
IC63 DZAA000978 OCTAL BUS BUFFER
IC64 DZZZ999999 Not Mounted
IC7 DZAA000734 DRAM
IC8 DZAA000977 VHMOS
or DZAA000727 VHMOS
IC9 DZZZ999999 Not Mounted
JP1 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W
JP10 DZZZ999999 Not Mounted
JP11 DZZZ999999 Not Mounted
JP12 DZZZ999999 Not Mounted
JP13 DZZZ999999 Not Mounted
JP14 DZZZ999999 Not Mounted
JP2 DZZZ999999 Not Mounted
JP3 DZZZ999999 Not Mounted
JP4 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
JP5 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
JP6 DZZZ999999 Not Mounted
JP7 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W
JP8 DZZZ999999 Not Mounted
JP9 DZZZ999999 Not Mounted
L1 DZDG000057 INDUCTOR
L2 DZDG000057 INDUCTOR
L3 DZDG000057 INDUCTOR
NF1 DZZZ999999 Not Mounted
NF10 DZZZ999999 Not Mounted
Safety
Mark
Ref. No. Part Number Part Name Description
