259

C61 DZZZ999999 Not Mounted - - - 1

C62 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC 1 1 1 1

C63 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC 1 1 1 1

C64 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC 1 1 1 1

C65 DZBA000167 CAPACITOR, CERAMIC 1000pF, 50VDC 1 1 1 1

C66 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC 1 1 1 1

C67 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC 1 1 1 1

C68 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC 1 1 1 1

C69 DZZZ999999 Not Mounted 1 1 1 1

C7 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C70 DZZZ999999 Not Mounted 1 1 1 1

C71 DZZZ999999 Not Mounted 1 1 1 1

C72 DZBA000045 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C73 DZBA000045 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C74 DZBA000045 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C75 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC 1 1 1 1

C76 DZBA000046 CAPACITOR, CERAMIC 0.1µF, 50VDC 1 1 1 1

C77 DZBA000045 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C78 DZZZ999999 Not Mounted 1 1 1 1

C79 DZZZ999999 Not Mounted 1 1 1 1

C8 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C9 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

CNP160 DZFC000313 CONNECTOR 1 1 1 1

CNP161 DZFC000072 CONNECTOR 1 1 1 1

CNP162 DZZZ999999 Not Mounted 1 1 1 1

D1 MA152A DIODE 1 1 1 1

D2 MA157A DIODE 1 1 1 1

D3 MA157A DIODE 1 1 1 1

IC1 DZAA001060 FLASH MEMORY 1 1 1 1

or DZAA001091 FLASH MEMORY 1 1 1 1

IC10 DZAA000038 OP-AMP 1 1 1 1

IC2 DZZZ999999 Not Mounted 1 1 1 1

IC3 MN86064A-1 CODEC 1 1 1 1

or MN86064A-2 CODEC 1 1 1 -

IC4 DZAD000673 MDM ROM 1 1 1 1

IC5 DZAA000762 SRAM 1 1 1 1

IC6 MN195004MFN1 QFX-2 1 1 1 1

IC7 DZAA000516 FAX ANALOG LSI 1 1 1 1

IC8 DZAA000038 OP-AMP 1 1 1 1

IC9 DZAC000084 ANALOG MASTER SLICE2 1 1 1 1

JP1 DZZZ999999 Not Mounted 1 1 1 1

JP10 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W 1 1 1 1

JP11 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W 1 1 1 1

JP12 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W 1 1 1 1

JP2 DZZZ999999 Not Mounted 1 1 1 1

JP3 DZZZ999999 Not Mounted 1 1 1 1

JP4 DZZZ999999 Not Mounted 1 1 1 1

JP5 DZZZ999999 Not Mounted 1 1 1 1

JP6 DZZZ999999 Not Mounted 1 1 1 1

JP7 ERJ3GEY0R00B RESISTOR, CHIP 0Ω , 1/16W 1 1 1 1

JP8 ERJ3GEY0R00B RESISTOR, CHIP 0Ω , 1/16W 1 1 1 1

JP9 ERJ3GEY0R00B RESISTOR, CHIP 0Ω , 1/16W 1 1 1 1

NF1 DZDL000002 FILTER, TIP EMI 1 1 1 1

NF2 DZDN000010 Chip Solid Inductor 1 1 1 1

NF3 DZDN000095 CHIP INDUCTOR 1 1 1 1

NF4 DZDN000095 CHIP INDUCTOR 1 1 1 1

NF5 DZDN000095 CHIP INDUCTOR 1 1 1 1

NF6 DZDN000095 CHIP INDUCTOR 1 1 1 1

NF7 DZZZ999999 Not Mounted 1 1 1 1

NF8 DZDN000095 CHIP INDUCTOR 1 1 1 1

OSC1 DZDP000072 CRYSTAL UNIT 1 1 1 1

or DZDP000191 CRYSTAL UNIT 1 1 1 1

PCB DZEP000476 PC BOARD, FAX 1 1 1 1

Safety

Mark

Ref.

No.

Part Number Part Name Description

AA,AB,AD,AF,AG

AH,AJ,AM,AN,AP

AQ,AR,AS,AV,EE

YG,YJ,YW

AE,AT,ED,YA

YB,YE,YF,YM

YN,YR,YS,YT

YU,YV,YX
