260
Q1 2SB1321A PNP SILICON TRANSISTOR 1 1 1 1
Q2 2SD1992A NPN SILICON TRANSISTOR 1 1 1 1
R1 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W 1 1 1 1
R100 ERJ3GEYJ330B RESISTOR, CHIP 33Ω, 1/16W 1 1 1 1
R101 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W 1 1 1 1
R102 ERJ3GEYJ330B RESISTOR, CHIP 33Ω, 1/16W 1 1 1 1
R103 ERJ3GEYJ330B RESISTOR, CHIP 33Ω, 1/16W 1 1 1 1
R104 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W 1 1 1 1
R105 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W 1 1 1 1
R106 DZZZ999999 Not Mounted 1 1 1 1
R107 DZZZ999999 Not Mounted 1 1 1 1
R108 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W 1 1 1 1
R109 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W 1 1 1 1
R11 DZZZ999999 Not Mounted 1 1 1 1
R110 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W 1 1 1 1
R111 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W 1 1 1 1
R112 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W 1 1 1 1
R113 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W 1 1 1 1
R12 DZZZ999999 Not Mounted 1 1 1 1
R13 ERJ3GEYJ472B RESISTOR, CHIP 4.7KΩ, 1/16W 1 1 1 1
R14 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ, 1/16W 1 1 1 1
R15 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1
R16 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1
R17 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1
R18 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1
R19 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1
R2 DZZZ999999 Not Mounted 1 1 1 1
R20 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1
R21 ERJ3GEYJ680B RESISTOR, CHIP 68Ω, 1/16W 1 1 1 1
R22 ERJ3GEYJ680B RESISTOR, CHIP 68Ω, 1/16W 1 1 1 1
R23 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W 1 1 1 1
R24 DZZZ999999 Not Mounted 1 1 1 1
R25 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ, 1/16W 1 1 1 1
R26 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W 1 1 1 1
R27 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ, 1/16W 1 1 1 1
R28 ERJ3GEYJ4R7B RESISTOR, CHIP 4.7Ω, 1/16W 1 1 1 1
R29 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1
R3 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W 1 1 1 1
R30 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ, 1/16W 1 1 1 1
R31 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1
R32 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W 1 1 1 1
R33 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1
R34 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1
R35 ERJ3GEYJ473B RESISTOR, CHIP 47KΩ, 1/16W 1 1 1 1
R36 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W 1 1 1 1
R37 ERJ3GEYJ333B RESISTOR, CHIP 33KΩ, 1/16W 1 1 1 1
R38 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1
R39 ERJ3GEYJ224B RESISTOR, CHIP 220KΩ, 1/16W 1 1 1 1
R4 ERJ3GEYJ100B RESISTOR, CHIP 10Ω, 1/16W 1 1 1 1
R40 ERJ3GEYJ823B RESISTOR, CHIP 83Ω, 1/16W 1 1 1 1
R41 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W 1 1 1 1
R42 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1
R43 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ, 1/16W 1 1 1 1
R44 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W 1 1 1 1
R45 ERJ3GEYJ333B RESISTOR, CHIP 33KΩ, 1/16W 1 1 1 1
R46 ERJ3GEYJ752B RESISTOR, CHIP 7.5Ω, 1/16W 1 1 1 1
R47 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W 1 1 1 1
R48 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ, 1/16W 1 1 1 1
R49 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W 1 1 1 1
R5 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1
R50 DZZZ999999 Not Mounted 1 1 1 1
R51 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1
R52 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1
R53 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1
Safety
Mark
Ref.
No.
Part Number Part Name Description
AA,AB,AD,AF,AG
AH,AJ,AM,AN,AP
AQ,AR,AS,AV,EE
YG,YJ,YW
AC
AU
YY
AE,AT,ED,YA
YB,YE,YF,YM
YN,YR,YS,YT
YU,YV,YX
AK
AL
AW
