261

R54 ERJ3GEYG103B RESISTOR, CHIP 1KΩ , 1/16W 1 1 1 1

R55 ERJ3GEYG473B RESISTOR, CHIP 47KΩ , 1/16W 1 1 1 1

R56 ERJ3GEYG223B RESISTOR, CHIP 22KΩ , 1/16W - - - 1

R56 ERJ3GEYG243B RESISTOR, CHIP 24KΩ , 1/16W - 1 - -

R56 ERJ3GEYG123B RESISTOR, CHIP 12KΩ , 1/16W - - 1 -

R56 ERJ3GEYG822B RESISTOR, CHIP 8.2KΩ , 1/16W 1 - - -

R57 ERJ3GEY0R00B RESISTOR, CHIP 0Ω , 1/16W - 1 1 -

R57 ERJ3GEYJ243B RESISTOR, CHIP 24KΩ , 1/16W 1 - - 1

R58 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ , 1/16W 1 - - 1

R58 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ , 1/16W - 1 1 -

R59 DZZZ999999 Not Mounted - 1 1 -

R59 ERJ3GEYJ221B RESISTOR, CHIP 220Ω , 1/16W 1 - - 1

R6 DZZZ999999 Not Mounted 1 1 1 1

R60 ERJ3GEYJ271B RESISTOR, CHIP 270Ω , 1/16W 1 - - 1

R60 DZZZ999999 Not Mounted - 1 1 -

R61 ERJ3GEYJ823B RESISTOR, CHIP 83Ω , 1/16W 1 1 1 1

R62 DZZZ999999 Not Mounted - 1 1 -

R62 ERJ3GEYJ101B RESISTOR, CHIP 100Ω , 1/16W 1 - - -

R62 ERJ3GEYJ820B RESISTOR, CHIP 82Ω , 1/16W - - - 1

R63 ERJ3GEYJ623B RESISTOR, CHIP 62KΩ , 1/16W - 1 1 -

R63 ERJ3GEYJ513B RESISTOR, CHIP 51KΩ , 1/16W 1 - - 1

R64 ERJ3GEYG561B RESISTOR, CHIP 560Ω , 1/16W 1 1 1 1

R65 ERJ3GEYJ513B RESISTOR, CHIP 51KΩ , 1/16W 1 1 1 1

R66 ERJ3GEYJ513B RESISTOR, CHIP 51KΩ , 1/16W - 1 1 -

R66 ERJ3GEYJ823B RESISTOR, CHIP 83Ω , 1/16W 1 - - 1

R67 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ , 1/16W 1 1 1 1

R68 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ , 1/16W 1 1 1 1

R69 ERJ3GEYJ101B RESISTOR, CHIP 100Ω , 1/16W 1 1 1 1

R7 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ, 1/16W 1 1 1 1

R70 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ , 1/16W 1 1 1 1

R71 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ , 1/16W 1 1 1 1

R72 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ , 1/16W 1 1 1 1

R73 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ , 1/16W 1 1 1 1

R74 ERJ3GEYJ101B RESISTOR, CHIP 100Ω , 1/16W 1 1 1 1

R75 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ , 1/16W 1 1 1 1

R76 ERJ3GEYJ273B RESISTOR, CHIP 27KΩ , 1/16W 1 1 1 -

R76 ERJ3GEY0R00B RESISTOR, CHIP 0Ω , 1/16W - - - 1

R77 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ , 1/16W 1 1 1 1

R78 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ , 1/16W 1 1 1 1

R79 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ , 1/16W 1 1 1 1

R8 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R80 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ , 1/16W 1 1 1 1

R81 DZZZ999999 Not Mounted - - - 1

R81 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ , 1/16W 1 1 1 -

R82 DZZZ999999 Not Mounted 1 1 1 1

R83 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ , 1/16W 1 1 1 1

R84 ERJ3GEYJ273B RESISTOR, CHIP 27KΩ , 1/16W 1 1 1 -

R84 DZZZ999999 Not Mounted - - - 1

R85 DZZZ999999 Not Mounted 1 1 1 1

R86 DZZZ999999 Not Mounted 1 1 1 1

R87 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ , 1/16W 1 1 1 1

R88 DZZZ999999 Not Mounted 1 1 1 1

R89 ERJ3GEY0R00B RESISTOR, CHIP 0Ω , 1/16W 1 1 1 1

R9 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R90 ERJ3GEYJ330B RESISTOR, CHIP 33Ω , 1/16W 1 1 1 1

R91 ERJ3GEYJ330B RESISTOR, CHIP 33Ω , 1/16W 1 1 1 1

R92 ERJ3GEYJ330B RESISTOR, CHIP 33Ω , 1/16W 1 1 1 1

R93 ERJ3GEY0R00B RESISTOR, CHIP 0Ω , 1/16W 1 1 1 1

R94 ERJ3GEYJ330B RESISTOR, CHIP 33Ω , 1/16W 1 1 1 1

R95 ERJ3GEYJ330B RESISTOR, CHIP 33Ω , 1/16W 1 1 1 1

R96 ERJ3GEYJ330B RESISTOR, CHIP 33Ω , 1/16W 1 1 1 1

R97 ERJ3GEYJ100B RESISTOR, CHIP 10Ω , 1/16W 1 1 1 1

R98 ERJ3GEYJ101B RESISTOR, CHIP 100Ω , 1/16W 1 1 1 1

R99 DZZZ999999 Not Mounted 1 1 1 1

Safety

Mark

Ref.

No.

Part Number Part Name Description

AA,AB,AD,AF,AG

AH,AJ,AM,AN,AP

AQ,AR,AS,AV,EE

YG,YJ,YW

AE,AT,ED,YA

YB,YE,YF,YM

YN,YR,YS,YT

YU,YV,YX
