CNP7 DZFC000210 PH CONNECTOR
CNP8 DZFC000052 PH CONNECTOR
CNP9 DZFC000016 CONNECTOR
CP1 DZDW000143 FUSE
CP2 DZDW000109 FUSE
D1 MA721-(TX) DIODE
D2 MA721-(TX) DIODE
D3 DZAG000504 DIODE
D4 MA721-(TX) DIODE
D5 MA721-(TX) DIODE
IC1 DZAC000289 SINGLE CHIP CPU
or DZAC000279 SINGLE CHIP CPU
or DZAA001360 SINGLE CHIP CPU
or DZAC000288 SINGLE CHIP CPU
IC2 DZAA000969 MOTOR DRIVER
IC3 DZZZ999999 Not Mounted
IC4 DZAA002010 COMPARATOR
IC5 DZAA001983 OR GATE
IC6 DZAA002132 AND GATE
IC7 DZAA002070 TRIPLE INVERTER
NF1 DZDN000137 CHIP INDUCTOR
NF2 DZDN000095 CHIP INDUCTOR
NF3 DZDN000095 CHIP INDUCTOR
NF4 DZDN000095 CHIP INDUCTOR
NF5 DZDN000095 CHIP INDUCTOR
NF6 DZDN000095 CHIP INDUCTOR
NF7 DZDN000095 CHIP INDUCTOR
NF8 DZDN000095 CHIP INDUCTOR
PC1 DZAL000052 PHOTO-INTERRUPTER
PC2 DZAL000052 PHOTO-INTERRUPTER
PCB DZEP000472 PC Board, SCN
Q1 DZAF000347 NPN SILICON TRANSISTOR
Q2 DZAF000360 TRANSISTOR
Q3 DZAF000360 TRANSISTOR
Q4 DZAF000360 TRANSISTOR
R1 ERJ3GEYJ103V RESISTOR, CHIP 10kΩ, 1/10W
R10 ERJ3GEY0R00V RESISTOR, CHIP 0Ω, 1/10W
R11 ERJ3GEYJ103V RESISTOR, CHIP 10kΩ, 1/10W
R12 ERJ3GEY0R00V RESISTOR, CHIP 0Ω, 1/10W
R13 ERJ3GEYJ102V RESISTOR, CHIP 1kΩ, 1/10W
R14 ERJ3GEYJ103V RESISTOR, CHIP 10kΩ, 1/10W
R16 DZZZ999999 Not Mounted
R17 ERJ3GEYJ101V RESISTOR, CHIP 100Ω, 1/10W
R19 ERJ3GEYJ102V RESISTOR, CHIP 1kΩ, 1/10W
R2 DZZZ999999 Not Mounted
R20 ERJ3GEYJ273V RESISTOR, CHIP 27kΩ, 1/10W
R21 ERX1SJR47 RESISTOR, METAL FILM 0.47Ω, 1W
R23 ERX1SJR47 RESISTOR, METAL FILM 0.47Ω, 1W
R25 ERJ3GEYJ823V RESISTOR, CHIP 82kΩ, 1/10W
R26 ERJ3GEYJ823V RESISTOR, CHIP 82kΩ, 1/10W
R27 ERJ3GEYJ104V RESISTOR, CHIP 100kΩ, 1/10W
R28 ERJ3GEYJ471V RESISTOR, CHIP 470Ω, 1/10W
R29 ERJ3GEYJ471V RESISTOR, CHIP 470Ω, 1/10W
R3 DZZZ999999 Not Mounted
R30 ERJ3GEYJ102V RESISTOR, CHIP 1kΩ, 1/10W
R31 DZZZ999999 Not Mounted
R32 ERJ3GEYJ102V RESISTOR, CHIP 1kΩ, 1/10W
R33 DZZZ999999 Not Mounted
R34 ERJ3GEY0R00V RESISTOR, CHIP 0Ω, 1/10W
R35 ERJ3GEYJ102V RESISTOR, CHIP 1kΩ, 1/10W
R36 ERJ3GEYJ102V RESISTOR, CHIP 1kΩ, 1/10W
R37 DZZZ999999 Not Mounted
R38 ERJ3GEY0R00V RESISTOR, CHIP 0Ω, 1/10W
R39 ERJ3GEYJ103V RESISTOR, CHIP 10kΩ, 1/10W
R4 DZZZ999999 Not Mounted
R43 ERJ3GEYJ330V RESISTOR, CHIP 33Ω, 1/10W
Safety
Mark
Ref. No. Part Number Part Name Description
