297
R44 ERJ3GEYJ330V RESISTOR, CHIP 33Ω, 1/10W
R45 ERJ3GEYJ471V RESISTOR, CHIP 470Ω, 1/10W
R46 ERJ3GEYJ471V RESISTOR, CHIP 470Ω, 1/10W
R47 ERJ3GEY0R00V RESISTOR, CHIP 0Ω, 1/10W
R48 DZZZ999999 Not Mounted
R49 DZZZ999999 Not Mounted
R5 ERJ3GEY0R00V RESISTOR, CHIP 0Ω, 1/10W
R50 DZZZ999999 Not Mounted
R51 ERJ3GEYJ103V RESISTOR, CHIP 10kΩ, 1/10W
R52 ERJ3GEYJ103V RESISTOR, CHIP 10kΩ, 1/10W
R53 ERX1SJU1R0V RESISTOR, METAL FILM 1Ω, 1W
R54 ERJ3GEYJ103V RESISTOR, CHIP 10kΩ, 1/10W
R55 ERJ3GEYJ102V RESISTOR, CHIP 1kΩ, 1/10W
R56 ERJ3GEYJ123V RESISTOR, CHIP 12kΩ, 1/10W
R57 ERJ3GEYJ104V RESISTOR, CHIP 100kΩ, 1/10W
R58 ERJ3GEYJ333V RESISTOR, CHIP 33kΩ, 1/10W
R59 ERJ3GEYJ472V RESISTOR, CHIP 4.7kΩ, 1/10W
R6 DZZZ999999 Not Mounted
R60 ERJ3GEYJ154V RESISTOR, CHIP 150kΩ, 1/10W
R61 DZZZ999999 Not Mounted
R62 ERJ3GEYJ330V RESISTOR, CHIP 33Ω, 1/10W
R63 ERJ3GEYJ330V RESISTOR, CHIP 33Ω, 1/10W
R64 ERJ3GEYJ473V RESISTOR, CHIP 47kΩ, 1/10W
R65 ERJ3GEYJ472V RESISTOR, CHIP 4.7kΩ, 1/10W
R66 ERJ3GEY0R00V RESISTOR, CHIP 0Ω, 1/10W
R67 DZZZ999999 Not Mounted
R68 ERJ3GEY0R00V RESISTOR, CHIP 0Ω, 1/10W
R69 ERJ3GEYJ561V RESISTOR, CHIP 560Ω, 1/10W
R7 ERJ3GEY0R00V RESISTOR, CHIP 0Ω, 1/10W
R70 ERJ3GEYJ102V RESISTOR, CHIP 1kΩ, 1/10W
R71 ERJ3GEYJ102V RESISTOR, CHIP 1kΩ, 1/10W
R72 ERJ3GEYJ472V RESISTOR, CHIP 4.7kΩ, 1/10W
R8 ERJ3GEYJ101V RESISTOR, CHIP 100Ω, 1/10W
R9 ERJ3GEYJ330V RESISTOR, CHIP 33Ω, 1/10W
RA1 EXBV8V102JV CHIP RESISTOR ARRAY 1kΩ, 1/16W
RA10 EXBV8V330JV CHIP RESISTOR ARRAY 33kΩ, 1/16W
RA11 DZZZ999999 Not Mounted
RA12 EXBV8V102JV CHIP RESISTOR ARRAY 1kΩ, 1/16W
RA14 EXBV8V103JV CHIP RESISTOR ARRAY 10kΩ, 1/16W
RA15 EXBV8V103JV CHIP RESISTOR ARRAY 10kΩ, 1/16W
RA16 EXBV8V103JV CHIP RESISTOR ARRAY 10kΩ, 1/16W
RA17 EXBV8V330JV CHIP RESISTOR ARRAY 33kΩ, 1/16W
RA18 EXBV8V102JV CHIP RESISTOR ARRAY 1kΩ, 1/16W
RA19 EXBV8V102JV CHIP RESISTOR ARRAY 1kΩ, 1/16W
RA2 EXBV8V330JV CHIP RESISTOR ARRAY 33kΩ, 1/16W
RA20 EXBV8V102JV CHIP RESISTOR ARRAY 1kΩ, 1/16W
RA21 EXBV8V102JV CHIP RESISTOR ARRAY 1kΩ, 1/16W
RA22 EXBV8V102JV CHIP RESISTOR ARRAY 1kΩ, 1/16W
RA3 EXBV8V330JV CHIP RESISTOR ARRAY 33kΩ, 1/16W
RA4 EXBV8V330JV CHIP RESISTOR ARRAY 33kΩ, 1/16W
RA7 EXBV8V102JV CHIP RESISTOR ARRAY 1kΩ, 1/16W
RA8 EXBV8V102JV CHIP RESISTOR ARRAY 1kΩ, 1/16W
RA9 EXBV8V102JV CHIP RESISTOR ARRAY 1kΩ, 1/16W
X1 DZDP000335 CRYSTAL UNIT
Safety
Mark
Ref. No. Part Number Part Name Description
