307

C65 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C66 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C67 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C68 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C69 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C7 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C70 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C71 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C72 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C73 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C74 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C75 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C76 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C77 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C78 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C79 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C8 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C80 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C81 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C82 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C83 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C84 DZZZ999999 Not Mounted 1 1 1 1

C86 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C87 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C88 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C89 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C9 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C91 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C92 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C93 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C94 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C95 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C96 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C97 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C98 DZBA000175 CAPACITOR, CERAMIC 0.1µF, 25VDC 1 1 1 1

C99 DZZZ999999 Not Mounted 1 1 1 1

CNP131 DZFC000586 2PIECE CONNECTOR 1 1 1 1

CNP132 DZFC000252 PH CONNECTOR 1 1 1 1

CNP133 DZZZ999999 Not Mounted 1 1 1 1

CNP134 DZZZ999999 Not Mounted 1 1 1 1

CNP135 DZZZ999999 Not Mounted 1 1 1 1

CNP2 DZFC000310 CONNECTOR 1 1 1 1

D1 DZZZ999999 Not Mounted 1 1 1 1

D2 MA157A DIODE 1 1 1 1

D3 MA157A DIODE 1 1 1 1

D4 MA157A DIODE 1 1 1 1

D5 MA721 DIODE 1 1 1 1

D6 MA721 DIODE 1 1 1 1

IC1 DZAD000346 SH ROM 1 1 1 1

IC10 DZAA000724 AND GATE 1 1 1 1

IC11 DZAA000769 LMOS 1 1 1 1

IC14 DZAA000092 INVERTER 1 1 1 1

IC15 DZAC000166 GATE ARRAY 1 1 1 1

IC2 DZAA000030 1GATE C MOS LOGIC IC 1 1 1 1

IC26 MN86064 CODEC 1 1 1 1

or MN86064A-1 CODEC 1 1 1 1

or MN86064A-2 CODEC 1 1 - 1

IC27 DZAD000452 MDM ROM - - 1 -

IC27 DZAD000673 MDM ROM 1 1 - 1

IC28 DZAA000709 SRAM 1 1 1 1

or DZAA000737 SRAM 1 1 1 1

IC29 MN195004MFN1 QFX-2 1 1 1 1

IC3 DZAA000091 AND GATE 1 1 1 1

IC30 DZZZ999999 Not Mounted 1 1 1 1

Safety

Mark

Ref.

No.

Part Number Part Name Description

AA,AB,AD,AF,AG,AH

AJ,AM,AN,AP,AQ,AR

AS,AV,EE,YG,YJ,YW

AE,AT,ED,YA,YB

YE,YF,YM,YN,YR

YS,YT,YU,YV,YX
