308

IC31 DZAC000084 ANALOG MASTER SLICE2 1 1 1 1

IC32 DZAA000516 FAX ANALOG LSI 1 1 1 1

IC34 DZAA000734 DRAM 1 1 1 1

or DZAA000738 DRAM 1 1 1 1

IC37 DZAA000691 DUAL PORT RAM 1 1 1 1

IC4 DZAA000091 AND GATE 1 1 1 1

IC5 DZAC000020 GATE ARRAY 1 1 1 1

IC6 DZAA000428

3-TERMINAL POSITIVE

VOLTAGE REGULATOR

1111

IC7 DZZZ999999 Not Mounted 1 1 1 1

IC8 DZAA000038 OP-AMP 1 1 1 1

IC9 DZAA000038 OP-AMP 1 1 1 1

JP2 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W 1 1 1 1

NF1 DZDN000010 CHIP SOLID INDUCTOR 1 1 1 1

NF2 DZZZ999999 Not Mounted 1 1 1 1

NF3 DZZZ999999 Not Mounted 1 1 1 1

NF4 DZZZ999999 Not Mounted 1 1 1 1

NF5 ERJ6GEYJ330B RESISTOR, CHIP 33Ω, 1/10W 1 1 1 1

OSC3 DZDP000072 CRYSTAL UNIT 1 1 1 1

PCB DZEP000429 PC BOARD, G3B 1 1 1 1

Q1 DZAF000042 TRANSISTOR 1 1 1 1

R1 ERJ3GEYJ201B RESISTOR, CHIP 200Ω, 1/16W 1 1 1 1

R10 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R100 ERJ3GEYJ472B RESISTOR, CHIP 4.7KΩ, 1/16W 1 1 1 1

R101 DZZZ999999 Not Mounted 1 1 1 1

R102 DZZZ999999 Not Mounted 1 1 1 1

R103 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W 1 1 1 1

R104 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W 1 1 1 1

R105 ERJ3GEYJ333B RESISTOR, CHIP 33KΩ, 1/16W 1 1 1 1

R106 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R107 ERJ3GEYJ393B RESISTOR, CHIP 39KΩ, 1/16W 1 1 1 1

R108 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R109 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R11 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R110 DZZZ999999 Not Mounted 1 1 1 1

R111 DZZZ999999 Not Mounted 1 1 1 1

R112 ERJ3GEYJ473B RESISTOR, CHIP 47KΩ, 1/16W 1 1 1 1

R113 ERJ3GEYJ224B RESISTOR, CHIP 220KΩ, 1/16W 1 1 1 1

R114 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R115 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R116 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R117 ERJ3GEYJ273B RESISTOR, CHIP 27KΩ, 1/16W 1 1 1 1

R118 DZZZ999999 Not Mounted - - 1 -

R118 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 - 1

R119 ERJ3GEYJ273B RESISTOR, CHIP 27KΩ, 1/16W - 1 - -

R119 DZZZ999999 Not Mounted 1 - 1 1

R12 ERJ3GEYJ100B RESISTOR, CHIP 10Ω, 1/16W 1 1 1 1

R120 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R121 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R122 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R123 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R124 DZZZ999999 Not Mounted 1 1 1 1

R125 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ, 1/16W 1 1 1 1

R126 ERJ3GEYJ102B RESISTOR, CHIP 1KΩ, 1/16W 1 1 1 1

R127 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R128 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R129 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R13 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W 1 1 1 1

R130 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W 1 1 1 1

R131 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W 1 1 1 1

R132 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W 1 1 1 1

R133 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W 1 1 1 1

R134 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R135 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R136 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

Safety

Mark

Ref.

No.

Part Number Part Name Description

AA,AB,AD,AF,AG,AH

AJ,AM,AN,AP,AQ,AR

AS,AV,EE,YG,YJ,YW

AE,AT,ED,YA,YB

YE,YF,YM,YN,YR

YS,YT,YU,YV,YX
