309

R138 DZZZ999999 Not Mounted 1 1 1 1

R139 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W 1 1 1 1

R14 DZZZ999999 Not Mounted 1 1 1 1

R140 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R141 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W - 1 - 1

R141 ERJ3GEYJ243B RESISTOR, CHIP 24KΩ, 1/16W 1 - 1 -

R142 DZZZ999999 Not Mounted - 1 - 1

R142 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W 1 - 1 -

R143 ERJ3GEYG561B RESISTOR, CHIP 560Ω, 1/16W 1 1 1 1

R144 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R145 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R146 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R147 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R148 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R149 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R15 ERJ3GEYJ3R3B RESISTOR, CHIP 3.3Ω, 1/16W 1 1 1 1

R150 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R151 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R152 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R153 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R154 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W 1 1 1 1

R155 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R156 ERJ3GEYG103B RESISTOR, CHIP 1KΩ, 1/16W 1 1 1 1

R157 ERJ3GEYJ513B RESISTOR, CHIP 51KΩ, 1/16W - 1 - 1

R157 ERJ3GEYJ823B RESISTOR, CHIP 83Ω, 1/16W 1 - 1 -

R158 ERJ3GEYJ513B RESISTOR, CHIP 51KΩ, 1/16W 1 1 1 1

R159 ERJ3GEYJ823B RESISTOR, CHIP 83Ω, 1/16W 1 1 1 1

R16 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W 1 1 1 1

R160 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R161 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 - 1 -

R161 ERJ3GEYJ104B RESISTOR, CHIP 100KΩ, 1/16W - 1 - 1

R162 DZZZ999999 Not Mounted - 1 - 1

R162 ERJ3GEYJ221B RESISTOR, CHIP 220Ω, 1/16W 1 - 1 -

R163 ERJ3GEYG473B RESISTOR, CHIP 47KΩ, 1/16W 1 1 1 1

R164 ERJ3GEYG822B RESISTOR, CHIP 8.2KΩ, 1/16W 1 - - -

R164 ERJ3GEYG223B RESISTOR, CHIP 22KΩ, 1/16W - - 1 -

R164 ERJ3GEYG243B RESISTOR, CHIP 24KΩ, 1/16W - - - 1

R164 ERJ3GEYG123B RESISTOR, CHIP 12KΩ, 1/16W - 1 - -

R165 ERJ3GEYJ623B RESISTOR, CHIP 62KΩ, 1/16W - 1 - 1

R165 ERJ3GEYJ513B RESISTOR, CHIP 51KΩ, 1/16W 1 - 1 -

R166 DZZZ999999 Not Mounted - 1 - 1

R166 ERJ3GEYJ271B RESISTOR, CHIP 270Ω, 1/16W 1 - 1 -

R167 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R168 DZZZ999999 Not Mounted 1 1 1 1

R169 DZZZ999999 Not Mounted 1 1 1 1

R17 ERJ3GEYJ3R3B RESISTOR, CHIP 3.3Ω, 1/16W 1 1 1 1

R170 DZZZ999999 Not Mounted 1 1 1 1

R171 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W 1 1 1 1

R172 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R173 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R174 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R175 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R176 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R177 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R178 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R179 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R18 DZZZ999999 Not Mounted 1 1 1 1

R180 ERJ3GEYJ100B RESISTOR, CHIP 10Ω, 1/16W 1 1 1 1

R181 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R182 ERJ3GEYJ101B RESISTOR, CHIP 100Ω, 1/16W 1 1 1 1

R183 ERJ3GEYJ103B RESISTOR, CHIP 10KΩ, 1/16W 1 1 1 1

R184 ERJ3GEY0R00B RESISTOR, CHIP 0Ω, 1/16W 1 1 1 1

R185 ERJ3GEYJ473B RESISTOR, CHIP 47KΩ, 1/16W 1 1 1 1

R186 DZZZ999999 Not Mounted 1 1 1 1

R187 DZZZ999999 Not Mounted 1 1 1 1

Safety

Mark

Ref.

No.

Part Number Part Name Description

AA,AB,AD,AF,AG,AH

AJ,AM,AN,AP,AQ,AR

AS,AV,EE,YG,YJ,YW

AE,AT,ED,YA,YB

YE,YF,YM,YN,YR

YS,YT,YU,YV,YX
