7.2.5 Booting Time
The booting time is the time span from the execution of the instruction to the actual pulse
output.
Instruction
Pulse output
method
No. of
steps
Booting
time
30
∼200μs
CW/CCW
60
∼400μs
30
∼500μs
1)
F171_PulseOutput_Trapezoidal,
Trapezoidal control
F171_PulseOutput_Home,
Home return
Pulse/direction
60
∼700μs
1)
CW/CCW –
∼20μs
F172_PulseOutput_Jog,
JOG operation
Pulse/direction –
∼320μs
1)
CW/CCW –
∼30μs
Pulse output
F174_PulseOutput_DataTable,
Data table control
Pulse/direction –
∼330μs
1)
PWM output
F173_PulseOutput_PWM,
PWM output
– –
∼30μs
1)
If pulse/direction is set, there is a waiting time (∼300μs) between turning on the direction output and
executing the pulse output instruction.
