Panasonic FPG-XY64D2P-A - 12.1 General Specifications

Appendix
FPΣ User's Manual
274
12.1 General Specifications
Item Description
Rated operating voltage
24V DC
Operating voltage range
21.6–26.4V DC
C32
C28
4ms at 21.6V, 7ms at 24V, 10ms at 26.4V
Momentary power
off time
C24
3ms at 21.6V, 5ms at 24V, 8ms at 26.4V
Ambient temperature
0–+55°C
Storage temperature
-20–+70°C
Ambient humidity
30–85% RH (at 25°C non-condensing)
Storage humidity
30–85% RH (at 25°C non-condensing)
Input terminals/Output terminals↔Power supply
terminal/Function earth
C32
C28
Input terminals«Output terminals
500V AC for 1min
1)
Input terminals (X0–X7)/Input terminals (X8–
XF)↔Power supply terminal/Function earth
500V AC for 1min
1)
Output terminals«Power supply terminal/Function earth 1500V AC for 1min
1)
Input terminals (X0–X7)↔Input terminals (X8–XF)
500V AC for 1min
1)
Breakdown
voltage
C24
Input terminals (X0–X7)/Input terminals (X8–
XF)↔Output terminals
1500V AC for 1min
1)
Input terminals/Output terminals↔Power supply
terminal/Function earth
C32
C28
Input terminals«Output terminals
Input terminals (X0–X7)/Input terminals (X8–
XF)↔Power supply terminal/Function earth
Output terminals«Power supply terminal/Function earth
Input terminals (X0–X7)↔Input terminals (X8–XF)
Insulation
resistance
C24
Input terminals (X0–X7)/Input terminals (X8–
XF)↔Output terminals
Min. 100MΩ (measured
with a 500V DC megger)
Vibration resistance
10–55Hz, 1 cycle/min: double amplitude of 0.75mm, 10min on 3 axes
Shock resistance
98m/s
2
, 4 times on 3 axes
Noise immunity (Power
supply terminal)
1000Vp-p, with pulse widths 50ns and 1μs (based on in-house measurements)
Operation conditions
Free from corrosive gases and excessive dust
1)
Max. cutoff current: 10mA (without built-in varistor)
