Description
3 Waiting Time (Waiting Time Adjustment) :
Adjusts the waiting time for starting radiation at the start point of each line.
Apply to all line segment.
Setting a large value improves the marking disorder.
Too large value, however, makes the marking time longer.
Setting Range 0 to 100
Initial Value
0 (LP-MA00 / LP-SxxxW type / LP-Z series)
10 (LP-M series (except LP-MA00) / LP-Sxxx type)
4 Jump (Jump adjustment) :
Adjusts the waiting time for starting radiation at the start point of the line.
It is applied only to the lines which distance to the next line is long.
Setting a large value improves the disordered lines at the start points.
Setting a larger value makes the marking time longer.
Setting Range 0 to 100
Initial Value 0
5 Pre-scan Time :
The pre-scan time adjusts the start-up and fall times of the laser beam at the start/end points. Setting the scanning
period improves the too thick marking at the start/end points.
Setting larger value makes the marking time longer.
Setting Range 0.00 to 10.00 ms
Initial Value 0.00 ms
6 Point Rad. On/Off (Point Radiation ON/OFF Adjustment) :
Adjusts the on/off timing of the radiation for “2-10-6 Point Radiation Condition” (P.181).
On time species the waiting time for starting radiation.
Off time species the waiting time for moving to the next radiation points.
Setting a larger value makes the marking time longer.
Setting Range 0.00 to 9.99 ms
Initial Value 0.00 ms
7 Laser Pulse Width (LP-Z series only) :
Species the laser pulse width. The narrower the pulse width sets, the higher the peak power of the laser raises,
and the device can perform the marking more sharply.
Setting Range 30 ns, 100 ns, 200 ns (LP-Z130)*
* For the setting range of the other model, refer to “Input Setting Value by Series” (P.296).
