2-2 Functional Description
Functions Outline
3D Marking *3 The 3D marking function can set max.16 types per one le.
Applicable 3D shapes:
- Plane (slope/uneven)
- Cylinder (convex/concave)
- Horizontal Cone (convex/concave)
- Vertical Cone (convex/concave)
- Sphere (convex/concave)
* Marking to ying object with 3D setting cannot be performed without using the encoder.
* When performing marking to ying object with 3D setting, marking time cannot be
measured regardless of using or not using the encoder.
Marking order optimizing This allows rearranging of marking order of characters to shorten the time required for
marking.
Intersection offset This keeps the intersection points of characters from being engraved too deeply.
Counter marking The marking is performed sequentially according to the counter conditions you set.
(Count-up/Count-down)
Current date marking This allows marking of current date or time.
Expiry date marking This allows marking of date or time calculated by adding the specied period/time to the
current date or hour.
Lot marking This allows marking by replacing the current (expiry) date, time, and counter value with
specied character string for marking.
Time hold input The time hold signal equipped in I/O connector keeps the time and date at the timing of its
ON input.
By following the holding time, the functions based on the clock, such as current date,
expiry date, lot and counter reset at updating operate.
Logo data marking This allows marking of the drawing data in DXF/HPGL/BMP/JPEG/AI/EPS form. (DXF
format data may be directly imported into the laser marker. Other data needs to be
converted using the attached software in advance.)
Barcode marking Marking of various bar codes, 2D codes and composite codes is possible. Inputting
character data will automatically generate a bar code.
Processing Performance
function
Specify the coordinates for “Straight Line”, “Circle”, or “Arc”, and radiate the laser.
Arbitrary Point Irradiation
Function
Specify the coordinates for “Point” and exposure time, and radiate the laser.
Flying Object marking
function
Marking following the moving target object is possible according to the specied line
speed and encoder signal.
Step & Repeat This allows marking of character string in matrix state by specifying the numbers of Row/
Column and the Intervals.
Over-marking Overwriting marking is done according to the specied overwriting frequency and interval.
Rank marking A number of character strings are registered in the data table, and marking is done by
switching with the I/O signals.
External offset A number of marking coordinates are registered in the data table, and marking is done by
switching with the I/O signals.
Serial data marking Marking is performed, changing the marking character string using communication
command.
Bold character marking Mark a character string in bold.
Marking shape setting This allows for selection of marking shapes: “Straight Line”, “Proportional”, “Justify”, “Arc
outside (+)” and “Arc inside (-).”
Font selection This allows for selection of registered fonts for marking character (alphanumeric). Fonts
can be newly created and edited with the attached software.
Marking image display This allows displaying of characters or graphic to be marked on the image screen.
