Warning
Errors that notify of that the setting data are incorrect or laser radiation conditions are not met are output as warnings.
Marking operation cannot be started while any warning is active. Laser pumping maintains the state before the warning.
Release method of warning
1. Remove a cause of warning. If the warning cause is the wrong setting, correct the le data.
2. When the laser marker is under the remote mode, close the shutter by I/O or serial communication control.
In case of the following warning, the shutter control is unnecessary.
• E800: the warning occurs only while the specied one-shot output time and it is released automatically.
• E811: the warning occurs only during the laser stop 1 and OUTCOM. is opened, and then it is released automatically
when the laser stop 1 and OUTCOM. is closed.
3. If the warning occurs during the marking operation of the les in which the counter function is set, check if the counter
value is correct before restart the marking operation.
4. In case that marking is executed again, make sure that the warning output is turned on, and then open the internal
shutter.
ERROR
CODE
Error description Measures
E227
*4
Laser gate is not open.
• Since the returning to the original position of the laser
gate is not performed correctly, the laser gate cannot
be opened.
• The laser gate is not opened when the test marking,
laser check radiation, or laser power measurement is
started.
• Input the laser gate control signals for the
returning to the original position after start-up
of the laser marker.
• Before starting the test marking, laser check
radiation, or laser power measurement , input
the control signal to [L-GATE OP IN] on the
laser gate terminal from the external control
device.
E251
Detected a decrease in clock battery voltage. Reset date
and time.
Contact to our sales ofce.
While laser Marker power is on, reset “Date and
Time” in Environment Setting. When the power is
off, reset “Date and Time”.
E500
There is not enough free space.
The le cannot be registered.
Delete registered le and logo le.
E501 Cannot register setting because of memory error.
• Restart with key switch.
• When not recovered, contact our sales ofce.
E502
E503
Invalid le format in font le and logo le.
• Register the logo or font le again on the USB
screen.
• For the logo le, convert the logo data to
VEC format again with Logo data conversion
software.
E600 No setting le.
Set the marking data such as character, barcode
and logo.
E601 No font le.
• Register font le.
• Set a registered font to the font in character
condition.
E602 Lack of font memory.
Make font le smaller, or delete unnecessary font
le.
E603 No logo le. Register logo le.
E604 Included character not registered into font le.
Change characters.
Or set the font le containing the setting
characters.
