Panasonic LP-M200 - Mark Counter; Input the Function Character of the Lot

35
1-3-4 Mark Counter
Sample
0001 0002 0003 … 0998 0999 1000 0001 0002
Initial value (Init) : 1
End value (End) : 1000
Step : 1
Counter source (Source) : Trigger signal
Displayed number of digits (Figure) : 4
Display leading zeros (Zero Fill) : Enable
Type of base number : Base-10 (Decimal) number system
Set the counters shown above.
2. Input the function character of the lot.
1. Set the Lot.
Refer to “3. Set the marking layout” (P.19) and “4. Set the laser condition” (P.20), “1-2-3 Set the marking data” (P.17).
3. Set the conditions of the function character of the lot and laser.
Reference
• For details on the counter function, refer to “2-9-2 Counter” (P.120).
ME-LPMSZ-OP-7
