Type of manuals
For this product, the following manuals are prepared. Read each manuals and operate this product correctly and safely.
Save the manuals for future use.
Safety / Setup / Maintenance Guide
This manual describes the safety precautions and the items required for the introduction, installation and maintenance of
the laser marker.
• Precautions and safety measures: All users shall be required for reading this part.
• Specications and outer dimensions
• Setup and connecting method
• I/O control method (signal layout, I/O rating, timing chart etc.)
• Maintenance
• Troubleshooting
Operation Manual
This manual describes how to operate the laser marker and set the marking data using touch panel console or monitor
and mouse.
Laser Marker NAVI plus Operation Manual
This manual describes how to operate the laser marker and set the marking data using PC setting software “Laser
Marker NAVI plus”.
Serial Communication Guide
This manual describes the communication commands to control the laser marker externally using the serial
communication (RS-232C/Ethernet). It describes the communication conditions, communication data formats,
communication commands, and the control samples.
Mainly the machine builder and system integrator shall be required for reading this manual.
Reference
• PDF data of each manual are included on an attached CD-ROM “Laser Marker Utility”.
• To read the PDF manual, Adobe Reader (Version X or later) of Adobe Systems Incorporated is required.
