265
SQW0419
Wi-Fi
Operating the camera by connecting it to a smartphone
■
Using an Android device
• When reading a QR Code to connect
Start “Image App” (→260)
Select [ ] → [OK]
Read the QR Code displayed on this unit with “Image App”
(When you press [MENU/SET] on the camera, the QR code is displayed in an
enlarged size.)
• When the smartphone is connected to a wireless access point, it may take time to display QR
code.
• When connecting with SSID and password
Start “Image App” (→260)
• If a message appears stating that a camera search is in progress, close the message.
Select [ ]
Select the SSID displayed on this unit
Enter the password displayed on this unit (First time connecting only)
• If you check the item to display the password, you can confirm the password as you enter it.
Changing the connection method
To change the connection method, follow the steps below:
(When the connection is made using [Wi-Fi] in the [Setup] menu)
Press [DISP.] button
(When the connection is made by pressing [Wi-Fi] button)
→ [DISP.] button → [New Connection]
→ [Remote Shooting & View] → [DISP.] button
■
When connecting with [Via Network]
(On the camera)
Select [Via Network] and press [MENU/SET]
• Connect the camera to a wireless access point by following the connection method (→293).
(On your smartphone)
Set Wi-Fi function to “ON”
Select the wireless access point you connected to the camera, and set
Start “Image App” (→260)
To Next Page
