Names of parts
[MENU/SET]
(menu display/set/finish) (20)
Left cursor button ()
• Self-timer (52)
Down cursor button ()
• Macro Mode (49)
• AF Lock (AF Tracking) (36, 99)
Up cursor button ()
• Exposure Compensation (53)
• Auto Bracket (54)
• Multi Aspect (55)
• White Balance fine adjustment
(98)
Right cursor button ()
• Flash (47)
In this manual, the button that is used is shaded or indicated by.
Camera ON/OFF switch
(19)
Shutter button (34)
Mode dial (33)
Flash (47)
Self-timer indicator (52)/
AF Assist Lamp
(106)
Lens barrel
Lens
(7)
Zoom lever
(39)
Microphone (76, 106)
Speaker (22, 115)
LCD monitor
(6, 23, 46, 152, 158)
REC/PLAY switch
(32)
[EXPOSURE] button
(56, 57, 58)
[DISPLAY] button (46)
Q.MENU (Quick setting 112)/
Delete button
(45)
[AV OUT/
DIGITAL]
socket
(141, 144, 147)
[E.ZOOM] button (42)
The appearance, specifications, and screen display vary depending on the model that is used.
We recommend
using the supplied
hand strap to
avoid dropping
the camera.
For the DMC-TZ10/DMC-ZS7 (9)
Tripod receptacle
Card/Battery door (14)
Release lever (14)
DC coupler cover
(15)
