Panasonic PT-REQ12 Series

Chapter 4 Settings — [POSITION] menu
ENGLISH - 107
4) Press qw to switch the item.
[INTERNAL] Enlarges the size within the aspect range set with [SCREEN FORMAT].
[FULL] Enlarges or reduces the size using the entire display area set with [SCREEN FORMAT].
5) Press as to select [INTERLOCKED].
6) Press qw to switch the item.
[OFF] Sets the [VERTICAL] and [HORIZONTAL] zoom ratio.
[ON]
Uses [BOTH] to set zoom ratio. Image can be enlarged or reduced vertically and horizontally at the
same magnication.
7) Press as to select [VERTICAL] or [HORIZONTAL].
f If [ON] is selected, select [BOTH].
8) Press qw to adjust.
Note
f When the [POSITION] menu → [ASPECT] is set to anything other than [DEFAULT], [MODE] is not displayed.
[GEOMETRY]
You can correct various types of distortion in a projected image.
Unique image processing technology enables projection of a square image on a special screen shape.
The projected image can be made to look more natural by making topical correction as necessary.
1) Press as to select [GEOMETRY].
2) Press qw to switch the item.
f The items will switch each time you press the button.
[OFF] Does not perform geometric adjustment.
[KEYSTONE] Adjusts any trapezoidal distortion in the projected image.
[CORNER CORRECTION] Adjusts any distortion in the four corners of the projected image.
[CURVED CORRECTION] Adjusts any curved distortion in the projected image.
[PC-1]
Select this item when performing correction using a computer and “Geometric & Setup Management
Software”
*1
. Up to three correction data can be saved.
[PC-2]
[PC-3]
*1 “Geometric & Setup Management Software” can be downloaded from the following website.
https://panasonic.net/cns/projector/pass/
It is necessary to register and login to PASS to download.
Note
f The menu, logo, or waveform monitor display may run o󰀨 the screen when [GEOMETRY] is set.
f The edge blending adjustment may not be performed correctly depending on the environment when using the [ADVANCED MENU] menu →
[EDGE BLENDING] and [GEOMETRY] simultaneously.
f The [GEOMETRY] setting is disabled in the following cases, and the geometric adjustment function cannot be used.
g When the [ADVANCED MENU] menu → [QUAD PIXEL DRIVE] is set to [OFF]
However, it is not disabled when 1080/120p image, 1080/240 image or test patterns are projected.
f The image may disappear for a moment or may be disrupted while performing adjustment, but it is not a malfunction.
Setting [KEYSTONE] or [CURVED CORRECTION]
1) Press as to select [GEOMETRY].
2) Press qw to select [KEYSTONE] or [CURVED CORRECTION].
3) Press the <ENTER> button.
f The [GEOMETRY:KEYSTONE] or [GEOMETRY:CURVED CORRECTION] screen is displayed.
4) Press as to select the item to adjust.
5) Press qw to adjust.
