Chapter 4 Settings — [PROJECTOR SETUP] menu
176 - ENGLISH
[FIRMWARE VERSION] Displays the rmware version of the projector.
[INTAKE AIR TEMP.]
*1
Displays the intake air temperature status.
[OPTICS MODULE TEMP.]
*1
Displays the internal temperature status.
[EXHAUST AIR TEMP.]
*1
Displays the exhaust air temperature status.
[LIGHT1 TEMP.]
*1
Displays the light source 1 temperature status.
[LIGHT2 TEMP.]
*1
Displays the light source 2 temperature status.
[SELF TEST] Displays the self-diagnosis information.
[INPUT]
Displays the input terminal currently selected.
Displays the representative input terminal when one image is displayed with multiple input signals.
[SIGNAL NAME] Displays the input signal name.
[MEMORY NO.] Displays the memory number of the input signal.
[BACKUP INPUT STATUS]
Displays whether switching to the backup input signal is possible or not when [BACKUP INPUT
MODE] is set to [OFF]. (x page 122)
[NUMBER OF REGISTERED
SIGNAL]
Displays the number of registered signals.
[COOLING CONDITION] Displays the set cooling conditions.
[ATMOSPHERIC PRESSURE] Displays the atmospheric pressure.
[REMOTE2 STATUS] Displays the control status of the REMOTE2.
[AC VOLTAGE] Displays the input supply voltage.
[LENS] [LENS TYPE] Displays the projection lens type.
[ON COUNT] [POWER ON TIMES] Displays the number of times the power is turned on.
[UPGRADE KIT] [ET-NUK10]
Displays the activation status by the NFC Upgrade Kit (Model No.:
ET-NUK10).
Or, displays the status of the NFC function.
[ACTIVATED]: The NFC function can be used.
[NOT ACTIVATED]: The NFC function cannot be used.
[SLOT]
Displays the product model number of the Function Board installed in <SLOT>.
Also, the rmware version is displayed after the product model number.
[OPERATING MODE]
Displays the setting value of the [PROJECTOR SETUP] menu → [OPERATION SETTING] →
[OPERATING MODE].
[NORMAL] Displays the runtime of the light source with [OPERATING MODE] set to [NORMAL].
[ECO] Displays the runtime of the light source with [OPERATING MODE] set to [ECO].
[QUIET] Displays the runtime of the light source with [OPERATING MODE] set to [QUIET].
[USER1] Displays the runtime of the light source with [OPERATING MODE] set to [USER1].
[USER2] Displays the runtime of the light source with [OPERATING MODE] set to [USER2].
[USER3] Displays the runtime of the light source with [OPERATING MODE] set to [USER3].
[CONSOLIDATED RUNTIME]
*2
Converts the total runtime of the light sources with [OPERATING MODE] set to each item into the
time used with the [NORMAL] setting.
The consolidated runtime is used for a rough indication about when to perform maintenance when the
projector is used in combination of each item in [OPERATING MODE].
[ANGLE INFORMATION]
[ROLL ANGLE]
*3
Displays the horizontal swing angle based on the detection result of
the built-in angle sensor.
[PITCH ANGLE]
*3
Displays the vertical tilt angle based on the detection result of the
built-in angle sensor.
[SIGNAL INFORMATION]
[INPUT]
Displays the input terminal used for the projected image.
Displays the representative input terminal when one image is
displayed with multiple input signals.
[SIGNAL FORMAT] Displays the format of the input signal.
[LINK]
Displays the [SDI LINK] setting.
Displays the determination result of the signal when [AUTO] is set.
[SAMPLING]
Displays the sampling information and the color format of the input
signal.
[BIT DEPTH] Displays the gradation of the input signal.
[SIGNAL LEVEL] Displays the signal level of the input signal.
[GAMMA] Displays the [GAMMA] setting.
[COLOR SPACE] Displays the [COLOR SPACE] setting.
*1 The temperature status is indicated with text color (green/yellow/red) and bar scale. Use the projector within the range that the indication is
green.
*2 [CONSOLIDATED RUNTIME] can be obtained with the following calculation formula. Values obtained by the calculation formula contain a
slight error.
*3 The angle value displayed is relative to the benchmark (zero calibration reset state / zero calibration implementation state) selected on the
[ANGLE MONITOR] screen.
