Panasonic PT-REQ12 Series

Chapter 7 Appendix — Technical information
270 - ENGLISH
Control details
r LIGHT OUTPUT
This can be set in 256 steps between 100 % and 0 %.
Performance Parameter Default value
100 % 0
0… …
0 % 255
r INPUT SELECT (when [Art-Net CHANNEL SETTING] is set to [1])
Performance Parameter Default value
No operation 0-39
0HDMI1 40-47
No operation 48-255
r INPUT SELECT (when [Art-Net CHANNEL SETTING] is set to anything other than [1])
Performance Parameter Default value
No operation 0-31
0
HDMI1 32-39
HDMI2 40-47
DisplayPort 48-55
No operation 56-79
SLOT
*1
80-87
No operation 88-255
*1 Switches the input to SDI, DIGITAL LINK, PressIT, or SLOT.
SDI: When the optional 12G-SDI Terminal Board (Model No.: TY-SB01QS) is installed in <SLOT>
DIGITAL LINK: When the optional DIGITAL LINK Terminal Board (Model No.: TY-SB01DL) is installed in <SLOT>
PressIT: When the optional Wireless Presentation System Receiver Board (Model No.: TY-SB01WP) is installed in <SLOT>
SLOT: When the Function Board by other manufacturers is installed in <SLOT>
r LENS FUNCTION SELECT
Operate together with LENS CONTROL.
Performance Parameter Default value
No operation 0-15
0
LENS H SHIFT 16-31
LENS V SHIFT 32-47
LENS FOCUS 48-63
LENS ZOOM 64-79
Move to the home position 80-95
Load LENS MEMORY 1 96-111
Load LENS MEMORY 2 112-127
Load LENS MEMORY 3 128-143
No operation 144-255
r LENS CONTROL
Operate together with LENS FUNCTION SELECT.
Performance Parameter Default value
Lens adjustment
(
- ) High speed 0-31
100
(
- ) Low speed 32-63
(
- ) Fine adjustment 64-95
Operation stop 96-127
Lens adjustment
(+) Fine adjustment 128-159
(+) Low speed 160-191
(+) High speed 192-223
Execute command action 224-255
