1.5. Safety Parts Information
Safety Parts List:
There are special components used in this equipment which are important for safety.
These parts are marked by in the Schematic Diagrams, Exploded View & Replacement Parts List. It is essential that these
critical parts should be replaced with manufacturer’s specified parts to prevent shock, fire or other hazards. Do not modify the
original design without permission of manufacturer.
Safety Ref No. Part No. Part Name & Description Remarks
24 RGR0455L-A REAR PANEL
33 RKM0744-K2 TOP CABINET
301 RAE1048Z-V TRAVERSE ASS'Y
A2 K2CJ2YY00097 AC CORD
A3 RQT9980-B O/I BOOK (En)
PCB14 REP5143B SMPS P.C.B (RTL)
DZ1001 D4EAY511A127 SURGE ABSORBER (E.S.D)
Q1403 B3PBA0000579 PHOTO COUPLER (E.S.D)
Q1405 B3PBA0000579 PHOTO COUPLER (E.S.D)
Q1404 B3PBA0000579 PHOTO COUPLER (E.S.D)
Q1505 B3PBA0000579 PHOTO COUPLER (E.S.D)
F1001 K5D103BNA005 FUSE
F1401 K5G501YA0081 FUSE
F1501 K5G502Y00006 FUSE
L1001 G0B183J00002 LINE FILTER
L1002 G0B183J00002 LINE FILTER
T1401 G4DYA0000688 SWITCHING TRANSFORMER
T1501 G4DYA0000691 SWITCHING TRANSFORMER
T1502 G4DYA0000691 SWITCHING TRANSFORMER
P1001 K2AZYA000005 AC INLET
R1001 D0GF105JA048 1M 1/4W
R1002 D0GF105JA048 1M 1/4W
C1001 F0CAF224A105 0.22uF
C1002 F0CAF224A105 0.22uF
C1003 F1BAF1020030 1000pF
C1004 F1BAF1020030 1000pF
C1006 F0CAF104A105 0.1uF
C1518 F1BAF1020030 1000pF
